Delta DRC-12V100W1RZ (85W 12V)
- Buy 20 for $28.99 each and save 3%
- Buy 50 for $28.49 each and save 4%
- Buy 100 for $28.04 each and save 6%
Delta Single Output, Class II, NEC Class 2, LPS, OVC III, Industrial AC-DC Converter, DIN Rail Package, 85 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 12VDC, Output Current: 7A, Connection: Screw Terminal
More Details
The Delta DRC-12V100W1RZ is a industrial, 1 output, AC-DC power supply. The nominal output is 12 Volts DC at 7.1 amps, with a maximum power output of 85 watts. It accepts an AC input voltage of 85~264 and has an efficiency rating of 90%. The DRC-12V100W1RZ has a DIN Rail mount package type with an operating temperature range of -30C to +70C. It features a fanless design for silent operation and its dimensions are 3.44 (L) x 2.76 (W) x 2.17 (H) inches. If you have questions about this Delta AC-DC power supply please contact us through our web chat or call us (408-733-9090).
Delta DRC-12V100W1RZ Features
View More
DRC-100W Series Description: The Delta DRC-100W Series AC-DC DIN rail power supply, a high-performance model in the Chrome II family, delivers a powerful 100-watt output with voltage options of 12V, 24V, or 48V, equipped with screw terminal connections for secure and reliable wiring in demanding applications. Supporting universal AC input (85-264Vac), this unit is designed for advanced building automation, industrial IoT systems, and robust control panels, offering versatility for applications like smart security systems, industrial gateways, and high-power lighting controls. Its compact design complies with DIN 43880 standards for distribution boards, ensuring seamless integration into space-constrained environments. Operating reliably from -30°C to +70°C (see datasheet for derating) with startup capability at -40°C, the DRC-100W excels in extreme conditions, making it suitable for harsh industrial and outdoor setups. Certified to IEC/EN 60335-1, IEC 61558-1, and IEC 61558-2-16, it ensures top-tier electrical safety for building and household applications. Featuring double-isolated input for low leakage current and compliance with DOE VI energy efficiency standards, it minimizes no-load power consumption for enhanced sustainability. Adhering to EN 61000-6-4 Class B emission and EN 61000-6-2 immunity standards, it reduces electromagnetic interference. RoHS-compliant and built for long-term durability, the DRC-100W Series is an ideal solution for engineers seeking a compact, efficient, and high-capacity power supply for sophisticated automation and industrial applications.
For specific information on the Delta DRC-12V100W1RZ please view the datasheet
Other models in the DRC-100W series: 24 volt-DRC-24V100W1RZ; 48 volt-DRC-48V100W1RZ
| Price | $29.79 |
|---|---|
| Manufacturer | Delta |
| Application | Industrial (ITE) |
| Package Type | DIN Rail |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 7.1A |
| Power Output (W) | 85 |
| Length | 3.44in (87.38mm) |
| Width | 2.76in (70.10mm) |
| Height | 2.17in (55.12mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 90% |
| Weight (lbs) | 0.510000 |
| Country of Origin | India |
| Product Series | DRC-100W |
