Delta DRL-12V120W1EN (120W 12V)
- Buy 20 for $29.92 each and save 3%
- Buy 50 for $29.40 each and save 4%
- Buy 100 for $28.94 each and save 6%
Delta Single Output, Industrial AC-DC Converter, DIN Rail Package, 120 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 12VDC, Output Current: 10A, Connection: Screw Terminal
More Details
The Delta DRL-12V120W1EN is a industrial, 1 output, AC-DC power supply. The nominal output is 12 Volts DC at 10 amps, with a maximum power output of 120 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 88%. The DRL-12V120W1EN has a DIN Rail mount package type with an operating temperature range of -40C to +70C. It features a fanless design for silent operation and its dimensions are 4.87 (L) x 1.18 (W) x 4.6 (H) inches. If you have questions about this Delta AC-DC power supply please contact us through our web chat or call us (408-733-9090).
Delta DRL-12V120W1EN Features
View More
DRL-120W Series Description: The Delta DRL-120W Series AC-DC DIN rail power supplies deliver reliable, high-performance power for industrial applications, offering output voltage options of 12V, 24V, and 48V to suit diverse system requirements. Engineered as part of the LYTE II family, these 120-watt units are tailored for cost-conscious users seeking robust functionality without sacrificing quality. With universal AC input (90-264V) and convection-cooled design, they operate efficiently across a wide temperature range (-30°C to +50°C at full power, derating to +70°C at 230 Vac), ensuring dependable performance in demanding environments like factory automation, building automation, and process control. The DRL-120W Series supports constant current mode, making it ideal for powering inductive and capacitive loads, such as motors or complex control systems. Certified to IEC/EN/UL 62368-1 safety standards and compliant with RoHS environmental requirements, these power supplies meet stringent global regulations. They also adhere to EN 61000-6-4 Class B emission and EN 61000-6-2 immunity standards for heavy industrial settings, minimizing electromagnetic interference. Compact, DIN rail-mountable, and designed for longevity with high power density, the DRL-120W Series is a versatile solution for engineers and system integrators aiming to optimize industrial setups with reliable power delivery.
For specific information on the Delta DRL-12V120W1EN please view the datasheet
Other models in the DRL-120W series: 24 volt-DRL-24V120W1EN; 48 volt-DRL-48V120W1EN
| Price | $30.75 |
|---|---|
| Manufacturer | Delta |
| Application | Industrial (ITE) |
| Package Type | DIN Rail |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 10A |
| Power Output (W) | 120 |
| Length | 4.87in (123.70mm) |
| Width | 1.18in (29.97mm) |
| Height | 4.60in (116.84mm) |
| Cooling | Fanless |
| Operating Temperature | -40C ~ 70C (with derating) |
| Efficiency | 88% |
| Weight (lbs) | 1.000000 |
| Country of Origin | India |
| Product Series | DRL-120W |
