Mean Well SUS01M-12 (1W 12V)
Authorized MEAN WELL
Stocking Distributor
- Buy 5 for $4.14 each and save 1%
- Buy 10 for $4.11 each and save 2%
- Buy 20 for $4.06 each and save 3%
MEAN WELL Single Output Industrial DC-DC Converter, DIP16 Package, On Board Package, 1 Watts, Input Voltage Range: 10.8~13.2VDC, Output Voltage: 12VDC, Output Current: 84mA
More Details
The MEAN WELL SUS01M-12 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 10.8 VDC and 13.2 VDC with a nominal input of 12 Volts. The SUS01M-12 has a 12 Volt Output at 0.084 amps (1 watts). The operating temperature is -25~+71°C and comes with several safety marks including FCC/CE. The SUS01M-12, DC-DC converter, has a Board Mount DIP16 package type and its dimensions are 0.89 (L) x 0.39 (W) x 0.33 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SUS01M-12 Features
View More
For specific information on the MEAN WELL SUS01M-12 please view the datasheet
Other models in the SUS01 series: 5Vdc in, 5Vdc out-SUS01L-05;, 5Vdc in, 9Vdc out-SUS01L-09;, 5Vdc in, 12Vdc out-SUS01L-12;, 5Vdc in, 15Vdc out-SUS01L-15;, 12Vdc in, 5Vdc out-SUS01M-05;, 12Vdc in, 9Vdc out-SUS01M-09;, 12Vdc in, 15Vdc out-SUS01M-15;, 24Vdc in, 5Vdc out-SUS01N-05;, 24Vdc in, 9Vdc out-SUS01N-09;, 24Vdc in, 12Vdc out-SUS01N-12;, 24Vdc in, 15Vdc out-SUS01N-15;, 48Vdc in, 5Vdc out-SUS01O-05;, 48Vdc in, 9Vdc out-SUS01O-09;, 48Vdc in, 12Vdc out-SUS01O-12;, 48Vdc in, 15Vdc out-SUS01O-15;
| Price | $4.20 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, DIP16 |
| Power Output (W) | 1 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 10.8~13.2 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 84mA |
| Length | 0.89in (22.61mm) |
| Width | 0.39in (9.91mm) |
| Height | 0.33in (8.38mm) |
| Operating Temperature | -25C ~ 71C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 0.020000 |
| Product Series | SUS01 |
Get Help Finding the Right Power Supply: Power Requirement Form
