Mean Well SPWM-75-24DA2
- Buy 5 for $29.00 each and save 5%
- Buy 10 for $27.70 each and save 9%
- Buy 20 for $26.90 each and save 12%
MEAN WELL LED AC-DC, 77 Watts, 24VDC output, Constant Voltage, 5yr warranty
More Details
The MEAN WELL SPWM-75-24DA2 is a LED Power Supply, good to use in applications like architectural lighting, emergency lighting, LED display and singage. This Constant Voltage LED driver has a rated output voltage of 24VDC and an output current of 3.2A (max power output is 77 watts). The plastic case SPWM-75-24DA2 is a Dimmable driver, with an rating and 5 year manufacturer's warranty. Its dimensions are 290 (L) x 38 (W) x 28.5 (H) mm and the operational temperature range is -20C to +90C. The AC input range is 100~305 VAC, with an overall efficiency rating of 90%. If you have any questions please contact our LED Power Experts through our web chat or call (408-733-9090).
MEAN WELL SPWM-75-24DA2 Features
View More
SPWM-75 Series Description: The MEAN WELL SPWM-75 series is a 75W AC/DC constant voltage LED driver built for PWM dimming of LED strips. It outputs a fixed 3.2kHz high-frequency PWM signal, delivering smooth, flicker-free brightness control while keeping LED color temperature stable and light uniform even when powering long LED strip runs. The driver accepts 100 to 305VAC input and supports 156 to 410VDC, operating in a fanless, fully enclosed, Class II plastic housing cooled through free air convection. Efficiency reaches up to 90% in field applications with a typical full-load power factor above 0.95. The SPWM-75 series includes short circuit and overload hiccup auto-recovery protection, along with over voltage and over temperature shutdown depending on model type, all designed to reset automatically or by cycling AC power once the fault is cleared. With a long-life design and a 5 year warranty, SPWM-75 is a trusted power source for home LED lighting, decorative LED strips, architectural accents, and DALI-2 or 3-in-1 dimmed commercial LED strip systems.
For specific information on the MEAN WELL SPWM-75-24DA2 please view the datasheet
Other models in the SPWM-75 series: 12Vdc, 6.3A, dimming-SPWM-75-12; 12Vdc, 6.3A, dimming-SPWM-75-12DA2; 12Vdc, 6.3A, dimming-SPWM-75-12DA2Q; 24Vdc, 3.2A, dimming-SPWM-75-24; 24Vdc, 3.2A, dimming-SPWM-75-24DA2Q
| Price | $30.40 |
|---|---|
| Manufacturer | Mean Well |
| Application | LED |
| Number Outputs | 1 |
| Power Output (W) | 77 |
| Output Current 1 | 3.2A |
| AC Input (VAC) | 100~305 |
| Dimming | Dimming |
| LED Driving Method | Constant Voltage |
| Class 2 | No Class 2 |
| Length | 11.42in (290.00mm) |
| Width | 1.50in (38.00mm) |
| Height | 1.12in (28.50mm) |
| Package Type | Plastic Case |
| Operating Temperature | -20C ~ 90C (with derating) |
| Efficiency | 90% |
| Warranty (yrs) | 5 |
| Weight (lbs) | 0.620000 |
| Country of Origin | China |
| Product Series | SPWM-75 |
