Mean Well SPU01N-12 (1W 12V)
SKU
SPU01N-12
Authorized MEAN WELL
Stocking Distributor
$3.33
- Buy 5 for $3.29 each and save 1%
- Buy 10 for $3.26 each and save 2%
- Buy 20 for $3.22 each and save 3%
MEAN WELL Single Output Industrial DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 21.6~26.4VDC, Output Voltage: 12VDC, Output Current: 84mA
More Details
The MEAN WELL SPU01N-12 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 21.6 VDC and 26.4 VDC with a nominal input of 24 Volts. The SPU01N-12 has a 12 Volt Output at 0.084 amps (1 watts). The operating temperature is -40~+90°C and comes with several safety marks including CE. The SPU01N-12, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 7.112 (W) x 10.16 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SPU01N-12 Features
View More
For specific information on the MEAN WELL SPU01N-12 please view the datasheet
Other models in the SPU01 series: 5Vdc in, 5Vdc out-SPU01L-05;, 5Vdc in, 12Vdc out-SPU01L-12;, 5Vdc in, 15Vdc out-SPU01L-15;, 12Vdc in, 5Vdc out-SPU01M-05;, 12Vdc in, 12Vdc out-SPU01M-12;, 12Vdc in, 15Vdc out-SPU01M-15;, 24Vdc in, 5Vdc out-SPU01N-05;, 24Vdc in, 15Vdc out-SPU01N-15;
| Price | $3.33 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | On Board, SIP |
| Power Output (W) | 1 |
| Nominal DC Input (VDC) | 24 |
| Input Voltage Range (VDC) | 21.6~26.4 |
| Voltage - Output 1 (VDC) | 12.0 |
| Output Current | 84mA |
| Length | 0.77in (19.56mm) |
| Width | 0.28in (7.11mm) |
| Height | 0.40in (10.16mm) |
| Number Outputs | 1 |
| Operating Temperature | -40C ~ 90C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 0.020000 |
| Product Series | SPU01 |
