Mean Well SPBW03G-12 (3W 12V)
SKU
SPBW03G-12
Authorized MEAN WELL
Stocking Distributor
$9.71
- Buy 5 for $9.57 each and save 1%
- Buy 10 for $9.50 each and save 2%
- Buy 20 for $9.37 each and save 4%
MEAN WELL Single Output Industrial DC-DC Converter, SIP Package, On Board Package, 3 Watts, Input Voltage Range: 18~75VDC, Output Voltage: 12VDC, Output Current: 250mA
More Details
The MEAN WELL SPBW03G-12 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 18 VDC and 75 VDC with a nominal input of 48 Volts. The SPBW03G-12 has a 12 Volt Output at 0.25 amps (3 watts). The operating temperature is -40~+85°C and comes with several safety marks including CE. The SPBW03G-12, DC-DC converter, has a Board Mount SIP package type and its dimensions are 0.86 (L) x 0.36 (W) x 0.44 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SPBW03G-12 Features
View More
For specific information on the MEAN WELL SPBW03G-12 please view the datasheet
Other models in the SPBW03 series: 24Vdc in, 3.3Vdc out-SPBW03F-03;, 24Vdc in, 5Vdc out-SPBW03F-05;, 24Vdc in, 12Vdc out-SPBW03F-12;, 24Vdc in, 15Vdc out-SPBW03F-15;, 48Vdc in, 3Vdc out-SPBW03G-03;, 48Vdc in, 5Vdc out-SPBW03G-05;, 48Vdc in, 15Vdc out-SPBW03G-15;
| Price | $9.71 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, SIP |
| Power Output (W) | 3 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 18~75 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 250mA |
| Length | 0.86in (21.84mm) |
| Width | 0.36in (9.14mm) |
| Height | 0.44in (11.18mm) |
| Operating Temperature | -40C ~ 85C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 0.020000 |
| Product Series | SPBW03 |
Get Help Finding the Right Power Supply: Power Requirement Form
