Mean Well SPA01A-05 (1W 5V)
SKU
SPA01A-05
Authorized MEAN WELL
Stocking Distributor
$7.97
- Buy 5 for $7.86 each and save 1%
- Buy 10 for $7.80 each and save 2%
- Buy 20 for $7.69 each and save 4%
MEAN WELL Single Output Industrial DC-DC Converter, SIP Package, On Board Package, 1 Watts, Input Voltage Range: 9~18VDC, Output Voltage: 5VDC, Output Current: 200mA
More Details
The MEAN WELL SPA01A-05 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 9 VDC and 18 VDC with a nominal input of 12 Volts. The SPA01A-05 has a 5 volt output at 0.2 amps (1 watts). The operating temperature is -40~+90°C and comes with several safety marks including FCC/CE. The SPA01A-05, DC-DC converter, has a Board Mount SIP package type and its dimensions are 0.69 (L) x 0.30 (W) x 0.44 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SPA01A-05 Features
View More
For specific information on the MEAN WELL SPA01A-05 please view the datasheet
Other models in the SPA01 series: 12Vdc in, 12Vdc out-SPA01A-12;, 12Vdc in, 15Vdc out-SPA01A-15;, 24Vdc in, 5Vdc out-SPA01B-05;, 24Vdc in, 12Vdc out-SPA01B-12;, 24Vdc in, 15Vdc out-SPA01B-15;, 48Vdc in, 5Vdc out-SPA01C-05;, 48Vdc in, 12Vdc out-SPA01C-12;, 48Vdc in, 15Vdc out-SPA01C-15;
| Price | $7.97 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, SIP |
| Power Output (W) | 1 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 9~18 |
| Voltage - Output 1 (VDC) | 5 |
| Output Current 1 | 200mA |
| Length | 0.69in (17.53mm) |
| Width | 0.30in (7.62mm) |
| Height | 0.44in (11.18mm) |
| Operating Temperature | -40C ~ 90C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 0.020000 |
| Product Series | SPA01 |
Get Help Finding the Right Power Supply: Power Requirement Form
