Mean Well SMU01L-05 (1W 5.0V)
SKU
SMU01L-05
Authorized MEAN WELL
Stocking Distributor
$4.78
- Buy 5 for $4.71 each and save 1%
- Buy 10 for $4.68 each and save 2%
- Buy 20 for $4.62 each and save 3%
MEAN WELL Single Output Industrial DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 4.5~5.5VDC, Output Voltage: 5VDC, Output Current: 200mA
More Details
The MEAN WELL SMU01L-05 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 4.5 VDC and 5.5 VDC with a nominal input of 5 volts. The SMU01L-05 has a 5 volt output at 0.2 amps (1 watts). The operating temperature is -40~+90°C and comes with several safety marks including FCC/CE. The SMU01L-05, DC-DC converter, has a Board Mount package type and its dimensions are 11.684 (L) x 6.096 (W) x 10.16 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SMU01L-05 Features
View More
For specific information on the MEAN WELL SMU01L-05 please view the datasheet
Other models in the SMU01 series: 5Vdc in, 9Vdc out-SMU01L-09;, 5Vdc in, 12Vdc out-SMU01L-12;, 5Vdc in, 15Vdc out-SMU01L-15;, 12Vdc in, 5Vdc out-SMU01M-05;, 12Vdc in, 9Vdc out-SMU01M-09;, 12Vdc in, 12Vdc out-SMU01M-12;, 12Vdc in, 15Vdc out-SMU01M-15;, 24Vdc in, 5Vdc out-SMU01N-05;, 24Vdc in, 9Vdc out-SMU01N-09;, 24Vdc in, 12Vdc out-SMU01N-12;, 24Vdc in, 15Vdc out-SMU01N-15;
| Price | $4.78 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | On Board, SIP |
| Power Output (W) | 1 |
| Nominal DC Input (VDC) | 5 |
| Input Voltage Range (VDC) | 4.5~5.5 |
| Voltage - Output 1 (VDC) | 5.0 |
| Output Current | 200mA |
| Length | 0.46in (11.68mm) |
| Width | 0.24in (6.10mm) |
| Height | 0.40in (10.16mm) |
| Number Outputs | 1 |
| Operating Temperature | -40C ~ 90C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 0.020000 |
| Product Series | SMU01 |
Get Help Finding the Right Power Supply: Power Requirement Form
