Mean Well SKMW40F-03 (33W 3.3V)

SKMW40 Series Description: SKMW40 series are 40W isolated and regulated module type DC-DC converter with DIP 1"x1" package. It features international standard pins, a high efficiency up to 91%, wide working temperature range -40~+80°C, 2KVDC I/P-O/P isolation voltage, compliance to BS EN/EN55032 Class A/B with additional components, continuous-mode short circuit, overload, over voltage, over temperature, input under voltage protection, remote ON/OFF and trimmable output voltage etc. The models account for different input voltage 9~36V and 18~75V, 4:1 ultrawide input range, and various single output voltages, 3.3V/5V/12V/15V/24V, which are suitable for all kinds of systems, such as industrial control, telecommunication field, distributed power architecture, and many more.

For specific information on the MEAN WELL SKMW40F-03 please view the datasheet

Other models in the SKMW40 series: 9~36Vdc in, 5Vdc out-SKMW40F-05;, 9~36Vdc in, 12Vdc out-SKMW40F-12;, 9~36Vdc in, 15Vdc out-SKMW40F-15;, 9~36Vdc in, 24Vdc out-SKMW40F-24;, 18~75Vdc in, 3.3Vdc out-SKMW40G-03;, 18~75Vdc in, 5Vdc out-SKMW40G-05;, 18~75Vdc in, 12Vdc out-SKMW40G-12;, 18~75Vdc in, 15Vdc out-SKMW40G-15;, 18~75Vdc in, 24Vdc out-SKMW40G-24;
