Mean Well SKM10B-15 (10W 15V)
Authorized MEAN WELL
Stocking Distributor
- Buy 5 for $20.71 each and save 1%
- Buy 10 for $20.57 each and save 2%
- Buy 20 for $20.28 each and save 3%
MEAN WELL Single Output Industrial DC-DC Converter, 1 x 1in, On Board Package, 10 Watts, Input Voltage Range: 18~36VDC, Output Voltage: 15VDC, Output Current: 666mA
More Details
The MEAN WELL SKM10B-15 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 18 VDC and 36 VDC with a nominal input of 24 Volts. The SKM10B-15 has a 15 volt output at 0.666 amps (10 watts). The operating temperature is -40~+85°C and comes with several safety marks including CE. The SKM10B-15, DC-DC converter, has a Board Mount 1x1in package type and its dimensions are 1.00 (L) x 1.00 (W) x 0.40 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SKM10B-15 Features
View More
For specific information on the MEAN WELL SKM10B-15 please view the datasheet
Other models in the SKM10 series: 5Vdc in, 3.3Vdc out-SKM10E-03;, 5Vdc in, 5Vdc out-SKM10E-05;, 5Vdc in, 12Vdc out-SKM10E-12;, 5Vdc in, 15Vdc out-SKM10E-15;, 12Vdc in, 3.3Vdc out-SKM10A-03;, 12Vdc in, 5Vdc out-SKM10A-05;, 12Vdc in, 12Vdc out-SKM10A-12;, 12Vdc in, 15Vdc out-SKM10A-15;, 24Vdc in, 3.3Vdc out-SKM10B-03;, 24Vdc in, 5Vdc out-SKM10B-05;, 24Vdc in, 12Vdc out-SKM10B-12;, 48Vdc in, 3.3Vdc out-SKM10C-03;, 48Vdc in, 5Vdc out-SKM10C-05;, 48Vdc in, 12Vdc out-SKM10C-12;, 48Vdc in, 15Vdc out-SKM10C-15;
| Price | $21.01 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, 1 x 1 |
| Power Output (W) | 10 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 18~36 |
| Voltage - Output 1 (VDC) | 15 |
| Output Current 1 | 666mA |
| Length | 1.00in (25.40mm) |
| Width | 1.00in (25.40mm) |
| Height | 0.40in (10.16mm) |
| Operating Temperature | -40C ~ 85C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 0.040000 |
| Product Series | SKM10 |
Get Help Finding the Right Power Supply: Power Requirement Form
