Mean Well SKE15C-05 (15W 5V)
SKU
SKE15C-05
Authorized MEAN WELL
Stocking Distributor
$20.14
- Buy 5 for $19.86 each and save 1%
- Buy 10 for $19.72 each and save 2%
- Buy 20 for $19.44 each and save 3%
MEAN WELL Single Output Industrial DC-DC Converter, 2 x 2in, On Board Package, 15 Watts, Input Voltage Range: 36~72VDC, Output Voltage: 5VDC, Output Current: 3000mA
More Details
The MEAN WELL SKE15C-05 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 36 VDC and 72 VDC with a nominal input of 48 Volts. The SKE15C-05 has a 5 volt output at 3 amps (15 watts). The operating temperature is -25~+71°C and comes with several safety marks including FCC/CE. The SKE15C-05, DC-DC converter, has a Board Mount 2x2in package type and its dimensions are 2.00 (L) x 2.00 (W) x 0.43 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SKE15C-05 Features
View More
For specific information on the MEAN WELL SKE15C-05 please view the datasheet
Other models in the SKE15 series: 12Vdc in, 5Vdc out-SKE15A-05;, 12Vdc in, 12Vdc out-SKE15A-12;, 12Vdc in, 15Vdc out-SKE15A-15;, 12Vdc in, 24Vdc out-SKE15A-24;, 24Vdc in, 5Vdc out-SKE15B-05;, 24Vdc in, 12Vdc out-SKE15B-12;, 24Vdc in, 15Vdc out-SKE15B-15;, 24Vdc in, 24Vdc out-SKE15B-24;, 48Vdc in, 12Vdc out-SKE15C-12;, 48Vdc in, 15Vdc out-SKE15C-15;, 48Vdc in, 24Vdc out-SKE15C-24;
| Price | $20.14 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, 2 x 2 |
| Power Output (W) | 15 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 36~72 |
| Voltage - Output 1 (VDC) | 5 |
| Output Current 1 | 3000mA |
| Length | 2.00in (50.80mm) |
| Width | 2.00in (50.80mm) |
| Height | 0.43in (10.92mm) |
| Operating Temperature | -25C ~ 71C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 0.150000 |
| Product Series | SKE15 |
