Mean Well SKA40C-12 (40W 12V)
SKU
SKA40C-12
Authorized MEAN WELL
Stocking Distributor
$40.51
- Buy 5 for $40.40 each and save 0%
- Buy 10 for $40.29 each and save 1%
- Buy 20 for $39.87 each and save 2%
MEAN WELL Single Output Industrial DC-DC Converter, 2 x 2in, On Board Package, 40 Watts, Input Voltage Range: 36~75VDC, Output Voltage: 12VDC, Output Current: 3330mA
More Details
The MEAN WELL SKA40C-12 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 36 VDC and 75 VDC with a nominal input of 48 Volts. The SKA40C-12 has a 12 Volt Output at 3.33 amps (40 watts). The operating temperature is -40~+80°C and comes with several safety marks including FCC/CE. The SKA40C-12, DC-DC converter, has a Board Mount 2x2in package type and its dimensions are 2.00 (L) x 2.00 (W) x 0.43 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SKA40C-12 Features
View More
For specific information on the MEAN WELL SKA40C-12 please view the datasheet
Other models in the SKA40 series: 12Vdc in, 5Vdc out-SKA40A-05;, 12Vdc in, 12Vdc out-SKA40A-12;, 12Vdc in, 15Vdc out-SKA40A-15;, 24Vdc in, 5Vdc out-SKA40B-05;, 24Vdc in, 12Vdc out-SKA40B-12;, 24Vdc in, 15Vdc out-SKA40B-15;, 48Vdc in, 5Vdc out-SKA40C-05;, 48Vdc in, 15Vdc out-SKA40C-15;
| Price | $40.51 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, 2 x 2 |
| Power Output (W) | 40 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 36~75 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 3330mA |
| Length | 2.00in (50.80mm) |
| Width | 2.00in (50.80mm) |
| Height | 0.43in (10.92mm) |
| Operating Temperature | -40C ~ 80C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 0.150000 |
| Product Series | SKA40 |
