Mean Well SKA20B-12 (20W 12V)
SKU
SKA20B-12
Authorized MEAN WELL
Stocking Distributor
$27.54
- Buy 5 for $27.14 each and save 1%
- Buy 10 for $26.95 each and save 2%
- Buy 20 for $26.57 each and save 4%
MEAN WELL Single Output Industrial DC-DC Converter, 2 x 1in, On Board Package, 20 Watts, Input Voltage Range: 18~36VDC, Output Voltage: 12VDC, Output Current: 1666mA
More Details
The MEAN WELL SKA20B-12 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 18 VDC and 36 VDC with a nominal input of 24 Volts. The SKA20B-12 has a 12 Volt Output at 1.666 amps (20 watts). The operating temperature is -40~+85°C and comes with several safety marks including FCC/CE. The SKA20B-12, DC-DC converter, has a Board Mount 2x1in package type and its dimensions are 2.00 (L) x 1.00 (W) x 0.44 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SKA20B-12 Features
View More
For specific information on the MEAN WELL SKA20B-12 please view the datasheet
Other models in the SKA20 series: 12Vdc in, 5Vdc out-SKA20A-05;, 12Vdc in, 12Vdc out-SKA20A-12;, 12Vdc in, 15Vdc out-SKA20A-15;, 24Vdc in, 5Vdc out-SKA20B-05;, 24Vdc in, 15Vdc out-SKA20B-15;, 48Vdc in, 5Vdc out-SKA20C-05;, 48Vdc in, 12Vdc out-SKA20C-12;, 48Vdc in, 15Vdc out-SKA20C-15;
| Price | $27.54 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, 2 x 1 |
| Power Output (W) | 20 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 18~36 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 1666mA |
| Length | 2.00in (50.80mm) |
| Width | 1.00in (25.40mm) |
| Height | 0.44in (11.18mm) |
| Operating Temperature | -40C ~ 85C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 0.090000 |
| Product Series | SKA20 |
