Mean Well SGA60E18-P1J (60W 18V)
SKU
SGA60E18-P1J
Authorized MEAN WELL
Stocking Distributor
$26.79
- Buy 5 for $25.52 each and save 5%
- Buy 10 for $24.39 each and save 9%
- Buy 20 for $23.69 each and save 12%
MEAN WELL Single Output, Industrial AC-DC Converter, External-Wall Mount Package, 60 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 18VDC, Output Current: 3A, Connection: Barrel Plug - 2.1 x 5.5 x 11mm
More Details
The MEAN WELL SGA60E18-P1J is a industrial, single output, AC-DC power supply. The nominal output is 18 volts DC at 3.33 amps, with a maximum power output of 60 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 88%. The SGA60E18-P1J has an External or Adapter package type with an operating temperature range of -20C to +50C. It has a fanless design for silent operation and its dimensions are 3.68 (L) x 1.38 (W) x 2.03 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SGA60E18-P1J Features
View More
For specific information on the MEAN WELL SGA60E18-P1J please view the datasheet
Other models in the SGA60E series: 5 volt-SGA60E05-P1J; 7.5 volt-SGA60E07-P1J; 9 volt-SGA60E09-P1J; 12 volt-SGA60E12-P1J; 15 volt-SGA60E15-P1J; 24 volt-SGA60E24-P1J; 48 volt-SGA60E48-P1J
| Price | $26.79 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | External-Wall Mount |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 18 |
| Output Current 1 | 3.33A |
| Power Output (W) | 60 |
| Length | 3.68in (93.50mm) |
| Width | 1.38in (35.00mm) |
| Height | 2.03in (51.50mm) |
| Cooling | Fanless |
| Operating Temperature | -20C ~ 50C (with derating) |
| Efficiency | 88% |
| Weight (lbs) | 0.551250 |
| Product Series | SGA60E |
Get Help Finding the Right Power Supply: Power Requirement Form
