Mean Well SGA12U05-USB (12W 5V)
SKU
SGA12U05-USB
Authorized MEAN WELL
Stocking Distributor
$11.78
- Buy 5 for $11.22 each and save 5%
- Buy 10 for $10.73 each and save 9%
- Buy 20 for $10.42 each and save 12%
MEAN WELL Single Output, Industrial AC-DC Converter, External-Wall Mount Package, 12 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 5VDC, Output Current: 2A
More Details
The MEAN WELL SGA12U05-USB is a industrial, single output, AC-DC power supply. The nominal output is 5 volts DC at 2.4 amps, with a maximum power output of 12 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 80%. The SGA12U05-USB has an External or Adapter package type with an operating temperature range of -20C to +60C. It has a fanless design for silent operation and its dimensions are 2.45 (L) x 1.08 (W) x 1.56 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SGA12U05-USB Features
View More
For specific information on the MEAN WELL SGA12U05-USB please view the datasheet
Other models in the SGA12U series: 5 volt-SGA12U05-P1J; 7.5 volt-SGA12U07-P1J; 9 volt-SGA12U09-P1J; 12 volt-SGA12U12-P1J; 15 volt-SGA12U15-P1J; 18 volt-SGA12U18-P1J; 24 volt-SGA12U24-P1J; 48 volt-SGA12U48-P1J
| Price | $11.78 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | External-Wall Mount |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 5 |
| Output Current 1 | 2.40A |
| Power Output (W) | 12 |
| Length | 2.45in (62.20mm) |
| Width | 1.08in (27.40mm) |
| Height | 1.56in (39.70mm) |
| Cooling | Fanless |
| Operating Temperature | -20C ~ 60C (with derating) |
| Efficiency | 80% |
| Weight (lbs) | 0.242550 |
| Product Series | SGA12U |
