Mean Well SFTN01M-15 (1W 15V)
SKU
SFTN01M-15
Authorized MEAN WELL
Stocking Distributor
$5.07
- Buy 5 for $5.00 each and save 1%
- Buy 10 for $4.96 each and save 2%
- Buy 20 for $4.90 each and save 3%
MEAN WELL Single Output Industrial DC-DC Converter, SMD, On Board Package, 1 Watts, Input Voltage Range: 10.8~13.2VDC, Output Voltage: 15VDC, Output Current: 67mA
More Details
The MEAN WELL SFTN01M-15 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 10.8 VDC and 13.2 VDC with a nominal input of 12 Volts. The SFTN01M-15 has a 15 volt output at 0.067 amps (1 watts). The operating temperature is -40~+90°C and comes with several safety marks including CE. The SFTN01M-15, DC-DC converter, has a Board Mount SMD package type and its dimensions are 0.60 (L) x 0.42 (W) x 0.28 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL SFTN01M-15 Features
View More
For specific information on the MEAN WELL SFTN01M-15 please view the datasheet
Other models in the SFTN01 series: 5Vdc in, 5Vdc out-SFTN01L-05;, 5Vdc in, 12Vdc out-SFTN01L-12;, 5Vdc in, 15Vdc out-SFTN01L-15;, 12Vdc in, 5Vdc out-SFTN01M-05;, 12Vdc in, 12Vdc out-SFTN01M-12;, 24Vdc in, 5Vdc out-SFTN01N-05;, 24Vdc in, 12Vdc out-SFTN01N-12;, 24Vdc in, 15Vdc out-SFTN01N-15;
| Price | $5.07 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, SMD |
| Power Output (W) | 1 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 10.8~13.2 |
| Voltage - Output 1 (VDC) | 15 |
| Output Current 1 | 67mA |
| Length | 0.60in (15.24mm) |
| Width | 0.42in (10.67mm) |
| Height | 0.28in (7.11mm) |
| Operating Temperature | -40C ~ 90C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 0.020000 |
| Product Series | SFTN01 |
Get Help Finding the Right Power Supply: Power Requirement Form
