Mean Well RSP-75-7.5 (75W 7.5V)
SKU
RSP-75-7.5
Authorized MEAN WELL
Stocking Distributor
$33.10
- Buy 5 for $31.50 each and save 5%
- Buy 10 for $30.10 each and save 9%
- Buy 20 for $29.20 each and save 12%
MEAN WELL Single Output, Industrial AC-DC Converter, Enclosed Package, 75 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 7.5VDC, Output Current: 10A, Connection: Screw Terminal
More Details
The MEAN WELL RSP-75-7.5 is a industrial, single output, AC-DC power supply. The nominal output is 7.5 volts DC at 10 amps, with a maximum power output of 75 watts. It accepts an AC input voltage of 85~264 and has an efficiency rating of 84%. The RSP-75-7.5 has an Enclosed package type with an operating temperature range of -25C to +70C. It has a fanless design for silent operation and its dimensions are 6.26 (L) x 3.82 (W) x 1.18 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL RSP-75-7.5 Features
View More
For specific information on the MEAN WELL RSP-75-7.5 please view the datasheet
Other models in the RSP-75 series: 3.3 volt-RSP-75-3.3; 5 volt-RSP-75-5; 12 volt-RSP-75-12; 13.5 volt-RSP-75-13.5; 15 volt-RSP-75-15; 24 volt-RSP-75-24; 27 volt-RSP-75-27; 48 volt-RSP-75-48
| Price | $33.10 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 7.5 |
| Output Current 1 | 10A |
| Power Output (W) | 75 |
| Length | 6.26in (159.00mm) |
| Width | 3.82in (97.00mm) |
| Height | 1.18in (30.00mm) |
| Cooling | Fanless |
| Operating Temperature | -25C ~ 70C (with derating) |
| Efficiency | 84% |
| Weight (lbs) | 0.970200 |
| Country of Origin | China |
| Product Series | RSP-75 |
Get Help Finding the Right Power Supply: Power Requirement Form
