Mean Well RSDW60F-03 (40W 3.3V)
Authorized MEAN WELL
Stocking Distributor
- Buy 5 for $49.47 each and save 0%
- Buy 10 for $49.34 each and save 1%
- Buy 20 for $48.82 each and save 2%
MEAN WELL Single Output Industrial DC-DC Converter, 2 x 1in, On Board Package, 39.6 Watts, Input Voltage Range: 9~36VDC, Output Voltage: 3.3VDC, Output Current: 12A
More Details
The MEAN WELL RSDW60F-03 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 9 VDC and 36 VDC with a nominal input of 24 Volts. The RSDW60F-03 has a 3.3 volt output at 12 amps (39.6 watts). The operating temperature is -40~+85°C and comes with several safety marks including EAC/CE. The RSDW60F-03, DC-DC converter, has a Board Mount 2x1in package type and its dimensions are 2.00 (L) x 1.00 (W) x 0.41 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL RSDW60F-03 Features
View More
For specific information on the MEAN WELL RSDW60F-03 please view the datasheet
Other models in the RSDW60 series: 24Vdc in, 5Vdc out-RSDW60F-05;, 24Vdc in, 12Vdc out-RSDW60F-12;, 24Vdc in, 15Vdc out-RSDW60F-15;, 24Vdc in, 24Vdc out-RSDW60F-24;, 48Vdc in, 3.3Vdc out-RSDW60G-03;, 48Vdc in, 5Vdc out-RSDW60G-05;, 48Vdc in, 12Vdc out-RSDW60G-12;, 48Vdc in, 15Vdc out-RSDW60G-15;, 48Vdc in, 24Vdc out-RSDW60G-24;, 110Vdc in, 5Vdc out-RSDW60H-05;, 110Vdc in, 12Vdc out-RSDW60H-12;, 110Vdc in, 24Vdc out-RSDW60H-24;, 110Vdc in, 48Vdc out-RSDW60H-48;
| Price | $49.60 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, 2 x 1 |
| Power Output (W) | 40 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 9~36 |
| Voltage - Output 1 (VDC) | 3.3 |
| Output Current 1 | 12A |
| Length | 2.00in (50.80mm) |
| Width | 1.00in (25.40mm) |
| Height | 0.41in (10.50mm) |
| Operating Temperature | -40C ~ 85C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 1.010000 |
| Product Series | RSDW60 |
