Mean Well RSDW40F-05

SKU
RSDW40F-05
Image at top has 5 yellow stars, below it is the red Mean Well logo.Image at top has 5 yellow stars, below it is the red Mean Well logo.

  Authorized MEAN WELL

  Stocking Distributor

$40.78
  • Buy 5 for $40.67 each and save 0%
  • Buy 20 for $40.13 each and save 2%

Product images shown are for illustration purposes only and may not be an exact representation of the product.

MEAN WELL DC-DC Industrial 2x1in 40 watts 9~36VDC input 5VDC output

More Details
The MEAN WELL RSDW40F-05 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 24 Volts or can accept an input voltage between 9 VDC and 36 VDC. The RSDW40F-05 has an output voltage of 5 VDC at 8 amps (40 watts). The operating temperature is -40~+90°C and comes with several safety marks including EAC/CE. The RSDW40F-05 DC-DC converter is a package type and its dimensions are 50.8 (L) x 25.4 (W) x 10.5 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).

MEAN WELL RSDW40F-05

DC-DC Industrial 2 x 1in , On Board type power supplyInput range: 9~36 volts DC / Output: 5 volts DC, 8 amps, 40 wattsCompliance with EN50155 railway standard2"x1" compact size with low profile (10.5mm)

View More4:1 wide input rangeWide operating temperature range -40~+90 CNo minimum load requiredFully encapsulatedProtections: Short circuit (Continuous) / Overload / Over voltage / Over temperature / Input under voltage lock-out1.6KVDC, 3KVDC I/O isolation by modelsRemote ON/OFF control3 year warranty

For specific information on the MEAN WELL RSDW40F-05 please view the datasheet

Other models in the RSDW40 series: 24Vdc in, 3.3Vdc out-RSDW40F-03;, 24Vdc in, 12Vdc out-RSDW40F-12;, 24Vdc in, 15Vdc out-RSDW40F-15;, 48Vdc in, 3.3Vdc out-RSDW40G-03;, 48Vdc in, 5Vdc out-RSDW40G-05;, 48Vdc in, 12Vdc out-RSDW40G-12;, 48Vdc in, 15Vdc out-RSDW40G-15;, 110Vdc in, 5Vdc out-RSDW40H-05;, 110Vdc in, 12Vdc out-RSDW40H-12;, 110Vdc in, 24Vdc out-RSDW40H-24;, 110Vdc in, 48Vdc out-RSDW40H-48;

More Information
Price$40.78
ManufacturerMean Well
Package Type2 x 1, On Board
IndustryIndustrial
DC Input24
Voltage Output5.0
Power Output (W)40
