Mean Well RSD-300D-24 (300W 24V)
Authorized MEAN WELL
Stocking Distributor
- Buy 5 for $133.00 each and save 5%
- Buy 10 for $127.20 each and save 9%
- Buy 20 for $123.50 each and save 12%
MEAN WELL Single Output Industrial DC-DC Converter, Enclosed Package, 300 Watts, Input Voltage Range: 67.2~143VDC, Output Voltage: 24VDC, Output Current: 12.5A
More Details
The MEAN WELL RSD-300D-24 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 67.2 VDC and 143 VDC with a nominal input of 96 volts. The RSD-300D-24 has a 24 Volt Output at 12.5 amps (300 watts). The operating temperature is -40~+70°C and comes with several safety marks including CE. The RSD-300D-24, DC-DC converter, has a Enclosed package type and its dimensions are 8.50 (L) x 3.82 (W) x 1.57 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL RSD-300D-24 Features
View More
For specific information on the MEAN WELL RSD-300D-24 please view the datasheet
Other models in the RSD-300 series: 24Vdc in, 5Vdc out-RSD-300B-5;, 24Vdc in, 12Vdc out-RSD-300B-12;, 24Vdc in, 24Vdc out-RSD-300B-24;, 24Vdc in, 48Vdc out-RSD-300B-48;, 48Vdc in, 5Vdc out-RSD-300C-5;, 48Vdc in, 12Vdc out-RSD-300C-12;, 48Vdc in, 24Vdc out-RSD-300C-24;, 48Vdc in, 48Vdc out-RSD-300C-48;, 96Vdc in, 5Vdc out-RSD-300D-5;, 96Vdc in, 12Vdc out-RSD-300D-12;, 96Vdc in, 48Vdc out-RSD-300D-48;, 36Vdc in, 5Vdc out-RSD-300E-5;, 36Vdc in, 12Vdc out-RSD-300E-12;, 36Vdc in, 24Vdc out-RSD-300E-24;, 36Vdc in, 48Vdc out-RSD-300E-48;, 72Vdc in, 5Vdc out-RSD-300F-5;, 72Vdc in, 12Vdc out-RSD-300F-12;, 72Vdc in, 24Vdc out-RSD-300F-24;, 72Vdc in, 48Vdc out-RSD-300F-48;
| Price | $139.70 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| Power Output (W) | 300 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 67.2~143 |
| Voltage - Output 1 (VDC) | 24 |
| Output Current 1 | 12.5A |
| Length | 8.50in (216.00mm) |
| Width | 3.82in (97.00mm) |
| Height | 1.57in (40.00mm) |
| Operating Temperature | -40C ~ 70C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 2.650000 |
| Product Series | RSD-300 |
