Mean Well RSD-150D-24 (151W 24V)
SKU
RSD-150D-24
Authorized MEAN WELL
Stocking Distributor
$98.80
- Buy 5 for $94.10 each and save 5%
- Buy 10 for $90.00 each and save 9%
- Buy 20 for $87.40 each and save 12%
MEAN WELL Single Output Industrial DC-DC Converter, Enclosed Package, 151 Watts, Input Voltage Range: 67.2~143VDC, Output Voltage: 24VDC, Output Current: 6.3A
More Details
The MEAN WELL RSD-150D-24 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 67.2 VDC and 143 VDC with a nominal input of 96 volts. The RSD-150D-24 has a 24 Volt Output at 6.3 amps (151 watts). The operating temperature is -40~+70°C and comes with several safety marks including CE. The RSD-150D-24, DC-DC converter, has a Enclosed package type and its dimensions are 7.44 (L) x 3.03 (W) x 1.42 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL RSD-150D-24 Features
View More
For specific information on the MEAN WELL RSD-150D-24 please view the datasheet
Other models in the RSD-150 series: 24Vdc in, 5Vdc out-RSD-150B-5;, 24Vdc in, 12Vdc out-RSD-150B-12;, 24Vdc in, 24Vdc out-RSD-150B-24;, 48Vdc in, 5Vdc out-RSD-150C-5;, 48Vdc in, 12Vdc out-RSD-150C-12;, 48Vdc in, 24Vdc out-RSD-150C-24;, 96Vdc in, 5Vdc out-RSD-150D-5;, 96Vdc in, 12Vdc out-RSD-150D-12;
| Price | $98.80 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| Power Output (W) | 151 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 67.2~143 |
| Voltage - Output 1 (VDC) | 24 |
| Output Current 1 | 6.3A |
| Length | 7.44in (189.00mm) |
| Width | 3.03in (77.00mm) |
| Height | 1.42in (36.00mm) |
| Operating Temperature | -40C ~ 70C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 1.760000 |
| Product Series | RSD-150 |
Get Help Finding the Right Power Supply: Power Requirement Form
