Mean Well RS-15-3.3 (10W 3.3V)
SKU
RS-15-3.3
Authorized MEAN WELL
Stocking Distributor
$8.70
- Buy 5 for $8.30 each and save 5%
- Buy 10 for $8.00 each and save 8%
- Buy 20 for $7.70 each and save 11%
MEAN WELL Single Output, Industrial AC-DC Converter, Enclosed Package, 10 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 3.3VDC, Output Current: 3A, Connection: Screw Terminal
More Details
The MEAN WELL RS-15-3.3 is a industrial, single output, AC-DC power supply. The nominal output is 3.3 volts DC at 3 amps, with a maximum power output of 10 watts. It accepts an AC input voltage of 85~264 and has an efficiency rating of 72%. The RS-15-3.3 has an Enclosed package type with an operating temperature range of -20C to +70C. It has a fanless design for silent operation and its dimensions are 2.46 (L) x 2.01 (W) x 1.10 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL RS-15-3.3 Features
View More
For specific information on the MEAN WELL RS-15-3.3 please view the datasheet
Other models in the RS-15 series: 5 volt-RS-15-5; 12 volt-RS-15-12; 15 volt-RS-15-15; 24 volt-RS-15-24; 48 volt-RS-15-48
| Price | $8.70 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 3.3 |
| Output Current 1 | 3.0A |
| Power Output (W) | 10 |
| Length | 2.46in (62.50mm) |
| Width | 2.01in (51.00mm) |
| Height | 1.10in (28.00mm) |
| Cooling | Fanless |
| Operating Temperature | -20C ~ 70C (with derating) |
| Efficiency | 72% |
| Weight (lbs) | 0.286650 |
| Country of Origin | China |
| Product Series | RS-15 |
