Mean Well RQB60W12-110S54 (60W 54V)
SKU
RQB60W12-110S54
$76.75
MEAN WELL Single Output Industrial DC-DC Converter, Quarter Brick, On Board Package, 60 Watts, Input Voltage Range: 14~160VDC, Output Voltage: 54VDC, Output Current: 1.11A
More Details
The MEAN WELL RQB60W12-110S54 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 14 VDC and 160 VDC with a nominal input of 48 Volts. The RQB60W12-110S54 has a 54 volt output at 1.11 amps (60 watts). The operating temperature is -40~+90°C and comes with several safety marks including UR/CB/EAC/CE/UKCA. The RQB60W12-110S54, DC-DC converter, has a Board Mount package type and its dimensions are 2.28 (L) x 1.45 (W) x 0.50 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL RQB60W12-110S54 Features
View More
For specific information on the MEAN WELL RQB60W12-110S54 please view the datasheet
Other models in the RQB60W-S series: 14~160Vdc in, 5Vdc out-RQB60W12-110S05;, 14~160Vdc in, 12Vdc out-RQB60W12-110S12;, 14~160Vdc in, 24Vdc out-RQB60W12-110S24;, 14~160Vdc in, 48Vdc out-RQB60W12-110S48;
| Price | $76.75 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Board Mount, Quarter Brick |
| Power Output (W) | 60 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 14~160 |
| Voltage - Output 1 (VDC) | 54 |
| Output Current 1 | 1.11A |
| Length | 2.28in (57.90mm) |
| Width | 1.45in (36.80mm) |
| Height | 0.50in (12.70mm) |
| Operating Temperature | -40C ~ 90C (with derating) |
| Country of Origin | Taiwan |
| Weight (lbs) | 0.149940 |
| Product Series | RQB60W-S |
