Mean Well RPS-300-27C (300W 27V)
SKU
RPS-300-27C
Authorized MEAN WELL
Stocking Distributor
$65.60
- Buy 5 for $62.40 each and save 5%
- Buy 10 for $59.70 each and save 9%
- Buy 20 for $58.00 each and save 12%
MEAN WELL Single Output, Medical AC-DC Converter, Enclosed Package, 300 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 27VDC, Output Current: 11A, Connection: Screw Terminal
More Details
The MEAN WELL RPS-300-27C is a medical safety certified, single output, AC-DC power supply. The nominal output is 27 volts DC at 11.12 amps, with a maximum power output of 300 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 93%. The RPS-300-27C has an Enclosed package type with an operating temperature range of -30C to +70C. It has a fanless design for silent operation and its dimensions are 5.12 (L) x 3.41 (W) x 1.69 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL RPS-300-27C Features
View More
For specific information on the MEAN WELL RPS-300-27C please view the datasheet
Other models in the RPS-300-C series: 12 volt-RPS-300-12C; 15 volt-RPS-300-15C; 24 volt-RPS-300-24C; 48 volt-RPS-300-48C
| Price | $65.60 |
|---|---|
| Manufacturer | Mean Well |
| Application | Medical |
| Package Type | Enclosed |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 27 |
| Output Current 1 | 11.12A |
| Power Output (W) | 300 |
| Length | 5.12in (130.00mm) |
| Width | 3.41in (86.60mm) |
| Height | 1.69in (43.00mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 93% |
| Weight (lbs) | 1.256850 |
| Product Series | RPS-300-C |
Get Help Finding the Right Power Supply: Power Requirement Form
