IPD REL-110-1008 (110W 48V)
SKU
REL-110-1008
$111.23
- Buy 5 for $108.99 each and save 2%
- Buy 10 for $106.14 each and save 5%
- Buy 20 for $104.10 each and save 6%
IPD Single Output AC-DC Converter, Open Frame Package, 110 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 48VDC, Output Current: 2.3A
More Details
The Integrated Power Designs REL-110-1008 is a single output, AC-DC power supply. The nominal output is rated for 48 volts at 2.3 amps (110 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 87%. The REL-110-1008 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, features fanless design for quiet operation and its dimensions are 5 (L) x 3 (W) x 1.32 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
Integrated Power Designs REL-110-1008 Features
View More
For specific information on the IPD REL-110-1008 please view the datasheet
Other single output models in the REL-110 series: 2.5 volt-REL-110-1001; 3.3 volt-REL-110-1002; 5 volt-REL-110-1003; 12 volt-REL-110-1004; 15 volt-REL-110-1005; 24 volt-REL-110-1006; 28 volt-REL-110-1007
| Price | $111.23 |
|---|---|
| Manufacturer | IPD |
| Application | Industrial (ITE), Medical |
| Package Type | Open Frame |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 48 |
| Output Current 1 | 2.3A |
| Power Output (W) | 110 |
| Length | 5.00in (126.50mm) |
| Width | 3.00in (75.90mm) |
| Height | 1.32in (33.40mm) |
| Cooling | Fanless |
| Operating Temperature | 0C ~ 70C (with derating) |
| Efficiency | 87% |
| Weight (lbs) | 0.800000 |
| Country of Origin | U.S.A. |
| Product Series | REL-110 |
