Mean Well PSP-600-24 (600W 24V)
SKU
PSP-600-24
Authorized MEAN WELL
Stocking Distributor
$147.30
- Buy 5 for $140.30 each and save 5%
- Buy 10 for $134.10 each and save 9%
- Buy 20 for $130.20 each and save 12%
MEAN WELL Single Output, Industrial AC-DC Converter, Enclosed Package, 600 Watts, Input Voltage Range: 88~264VAC, Output Voltage: 24VDC, Output Current: 25A, Connection: Screw Terminal
More Details
The MEAN WELL PSP-600-24 is a industrial, single output, AC-DC power supply. The nominal output is 24 Volts DC at 25 amps, with a maximum power output of 600 watts. It accepts an AC input voltage of 88~264 and has an efficiency rating of 86%. The PSP-600-24 has an Enclosed package type with an operating temperature range of -20C to +60C. It includes a built-in fan for active cooling and its dimensions are 6.69 (L) x 4.72 (W) x 3.66 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL PSP-600-24 Features
View More
For specific information on the MEAN WELL PSP-600-24 please view the datasheet
Other models in the PSP-600 series: 5 volt-PSP-600-5; 12 volt-PSP-600-12; 13.5 volt-PSP-600-13.5; 15 volt-PSP-600-15; 27 volt-PSP-600-27; 48 volt-PSP-600-48
| Price | $147.30 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| AC Input (VAC) | 88~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 24 |
| Output Current 1 | 25A |
| Power Output (W) | 600 |
| Length | 6.69in (170.00mm) |
| Width | 4.72in (120.00mm) |
| Height | 3.66in (93.00mm) |
| Cooling | Fan Cooled |
| Operating Temperature | -20C ~ 60C (with derating) |
| Efficiency | 86% |
| Weight (lbs) | 4.299750 |
| Country of Origin | Taiwan, China |
| Product Series | PSP-600 |
Get Help Finding the Right Power Supply: Power Requirement Form
