Delta PMR-36V320W1AT (320W 36V)
- Buy 20 for $61.55 each and save 3%
- Buy 50 for $60.49 each and save 4%
- Buy 100 for $59.54 each and save 6%
Delta Single Output, Active PFC, Industrial AC-DC Converter, Enclosed Package, 320 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 36VDC, Output Current: 9A, Connection: Screw Terminal
More Details
The Delta PMR-36V320W1AT is a industrial, 1 output, AC-DC power supply. The nominal output is 36 volts DC at 8.9 amps, with a maximum power output of 320 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 93%. The PMR-36V320W1AT has an Enclosed package type with an operating temperature range of -30C to +70C. It includes a built-in fan for active cooling and its dimensions are 8.46 (L) x 4.53 (W) x 1.18 (H) inches. If you have questions about this Delta AC-DC power supply please contact us through our web chat or call us (408-733-9090).
Delta PMR-36V320W1AT Features
View More
PMR-320W Series Description: The Delta PMR-320W Series AC-DC panel-mount power supply, a high-performance model in the PMR family, delivers a formidable 320-watt output with voltage options of 12V, 24V, 36V, or 48V, featuring screw terminal connections for secure and robust wiring in demanding industrial applications. Designed for universal AC input (90-264Vac) or DC input (127-375Vdc), this unit incorporates active PFC to ensure high power factor and compliance with IEC/EN 61000-3-2 Class A and Class D harmonic current emission standards, making it ideal for heavy industrial automation, renewable energy systems, and advanced telecommunications equipment. Its slim 30mm low-profile design enables seamless installation in space-constrained environments, while its rugged construction meets IEC 60068-2 shock and vibration standards, ensuring durability in harsh settings like factory automation lines and outdoor power enclosures. Operating reliably from -30°C to +70°C (see datasheet for derating details) with startup capability at -40°C, the PMR-320W supports critical applications such as high-power motor drives, industrial edge computing, and large LED display systems. Certified to global safety standards and RoHS-compliant, it guarantees environmental and regulatory compliance. With exceptional efficiency and minimal power loss, the PMR-320W Series is a premier solution for engineers seeking a compact, high-capacity power supply for sophisticated industrial and commercial setups.
For specific information on the Delta PMR-36V320W1AT please view the datasheet
Other models in the PMR-320W series: 12 volt-PMR-12V320W1AT; 24 volt-PMR-24V320W1AT; 48 volt-PMR-48V320W1AT
| Price | $63.26 |
|---|---|
| Manufacturer | Delta |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 36 |
| Output Current 1 | 8.9A |
| Power Output (W) | 320 |
| Length | 8.46in (214.88mm) |
| Width | 4.53in (115.06mm) |
| Height | 1.18in (29.97mm) |
| Cooling | Fan Cooled |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 93% |
| Weight (lbs) | 1.420000 |
| Country of Origin | India |
| Product Series | PMR-320W |
