Delta PMR-12V150W1AT (150W 12V)
- Buy 20 for $36.43 each and save 3%
- Buy 50 for $35.80 each and save 4%
- Buy 100 for $35.24 each and save 6%
Delta Single Output, Active PFC, Industrial AC-DC Converter, Enclosed Package, 150 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 12VDC, Output Current: 13A, Connection: Screw Terminal
More Details
The Delta PMR-12V150W1AT is a industrial, 1 output, AC-DC power supply. The nominal output is 12 Volts DC at 12.5 amps, with a maximum power output of 150 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 93%. The PMR-12V150W1AT has an Enclosed package type with an operating temperature range of -30C to +70C. It features a fanless design for silent operation and its dimensions are 5.08 (L) x 3.82 (W) x 1.18 (H) inches. If you have questions about this Delta AC-DC power supply please contact us through our web chat or call us (408-733-9090).
Delta PMR-12V150W1AT Features
View More
PMR-150W Series Description: The Delta PMR-150W Series AC-DC panel-mount power supply, a high-efficiency model in the PMR family, delivers a robust 150-watt output with voltage options of 12V, 24V, 36V, or 48V, featuring screw terminal connections for secure and reliable wiring in demanding applications. Supporting a universal AC input range (90-264Vac) or DC input (127~375Vdc) with built-in active PFC, this unit ensures high power factor and compliance with IEC/EN 61000-3-2 Class A and Class D harmonic current emission standards, making it ideal for industrial automation, telecommunications equipment, and advanced control systems. Its low-profile 30mm design enables installation in tight spaces, while its rugged construction withstands shock and vibration per IEC 60068-2, ensuring durability in tough environments like factory floors and outdoor enclosures. Operating reliably from -30°C to +70°C with startup capability at -40°C, the PMR-150W excels in extreme conditions, supporting applications such as motor controllers, industrial PCs, and LED display systems. Certified to global safety standards and RoHS-compliant, it guarantees environmental and regulatory compliance. With high efficiency and low power consumption, the PMR-150W Series is a top choice for engineers seeking a compact, powerful, and dependable power solution for sophisticated industrial and commercial setups.
For specific information on the Delta PMR-12V150W1AT please view the datasheet
Other models in the PMR-150W series: 24 volt-PMR-24V150W1AT; 36 volt-PMR-36V150W1AT; 48 volt-PMR-48V150W1AT
| Price | $37.44 |
|---|---|
| Manufacturer | Delta |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 12.5A |
| Power Output (W) | 150 |
| Length | 5.08in (129.03mm) |
| Width | 3.82in (97.03mm) |
| Height | 1.18in (29.97mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 93% |
| Weight (lbs) | 0.770000 |
| Country of Origin | India |
| Product Series | PMR-150W |
Get Help Finding the Right Power Supply: Power Requirement Form
