Mean Well NSD05-48S12

SKU
NSD05-48S12
Image at top has 5 yellow stars, below it is the red Mean Well logo.Image at top has 5 yellow stars, below it is the red Mean Well logo.

  Authorized MEAN WELL

  Stocking Distributor

$8.55
  • Buy 5 for $8.43 each and save 1%
  • Buy 10 for $8.37 each and save 2%
  • Buy 20 for $8.25 each and save 4%

Product images shown are for illustration purposes only and may not be an exact representation of the product.

MEAN WELL DC-DC Industrial On Board 5 watts 18~72VDC input 12VDC output

More Details
The MEAN WELL NSD05-48S12 is a industrial, single output, DC-DC converter. This power supply has a nominal input voltage of 48 Volts or can accept an input voltage between 18 VDC and 72 VDC. The NSD05-48S12 has an output voltage of 12 VDC at 0.42 amps (5 watts). The operating temperature is -25~+70°C and comes with several safety marks including CB/CE. The NSD05-48S12 DC-DC converter is a On Board package type and its dimensions are 40.64 (L) x 25.4 (W) x 8.3058 (H) mm. If you have questions about this MEAN WELL DC-DC converter please contact us through email, online chat or call us (408-733-9090).

MEAN WELL NSD05-48S12

DC-DC Industrial On Board type power supplyInput range: 18~72 volts DC / Output: 12 volts DC, 0.4 amps, 5 wattsWide 4:1 DC input rangeProtections: Short circuit / Overload / Over voltage

View More1000VDC I/O isolationCooling by free air convectionBuilt-in remote ON-OFF control100% full load burn-in testLow costHigh reliability2 year warranty

For specific information on the MEAN WELL NSD05-48S12 please view the datasheet

Other models in the NSD05 series: 12Vdc in, 3.3Vdc out-NSD05-12S3;, 12Vdc in, 5Vdc out-NSD05-12S5;, 12Vdc in, 12Vdc out-NSD05-12S12;, 12Vdc in, 15Vdc out-NSD05-12S15;, 48Vdc in, 3.3Vdc out-NSD05-48S3;, 48Vdc in, 5Vdc out-NSD05-48S5;, 48Vdc in, 15Vdc out-NSD05-48S15;

More Information
Price$8.55
ManufacturerMean Well
Package TypeOn Board
IndustryIndustrial
DC Input48
Voltage Output12.0
Power Output (W)5
