Mean Well NPB-450-24NFC (454W 28.8V)
SKU
NPB-450-24NFC
$147.80
- Buy 5 for $140.80 each and save 5%
- Buy 10 for $134.60 each and save 9%
- Buy 20 for $130.70 each and save 12%
MEAN WELL Single Output, Battery Charger AC-DC Converter, Enclosed Package, 454 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 28.8VDC, Output Current: 14A, Connection: Screw Terminal
More Details
The MEAN WELL NPB-450-24NFC is a battery charger, single output, AC-DC power supply. The nominal output is 28.8 volts DC at 13.5 amps, with a maximum power output of 454 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 93%. The NPB-450-24NFC has an Enclosed package type with an operating temperature range of -30C to +70C. It includes a built-in fan for active cooling and its dimensions are 8.07 (L) x 5.31 (W) x 2.17 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL NPB-450-24NFC Features
View More
For specific information on the MEAN WELL NPB-450-24NFC please view the datasheet
Other models in the NPB-450-NFC series: 14.4 volt-NPB-450-12NFC; 57.6 volt-NPB-450-48NFC; 72 volt-NPB-450-72NFC
| Price | $147.80 |
|---|---|
| Manufacturer | Mean Well |
| Application | Battery Charger |
| Package Type | Enclosed |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 28.8 |
| Output Current 1 | 13.5A |
| Power Output (W) | 454 |
| Length | 8.07in (205.00mm) |
| Width | 5.31in (135.00mm) |
| Height | 2.17in (55.00mm) |
| Cooling | Fan Cooled |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 93% |
| Weight (lbs) | 2.249100 |
| Country of Origin | China |
| Product Series | NPB-450-NFC |
Get Help Finding the Right Power Supply: Power Requirement Form
