Mean Well MSP-450-15 (450W 15V)
SKU
MSP-450-15
Authorized MEAN WELL
Stocking Distributor
$172.00
- Buy 5 for $163.80 each and save 5%
- Buy 10 for $156.60 each and save 9%
- Buy 20 for $152.00 each and save 12%
MEAN WELL Single Output, Medical AC-DC Converter, Enclosed Package, 450 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 15VDC, Output Current: 30A, Connection: Screw Terminal
More Details
The MEAN WELL MSP-450-15 is a medical safety certified, single output, AC-DC power supply. The nominal output is 15 volts DC at 30 amps, with a maximum power output of 450 watts. It accepts an AC input voltage of 85~264 and has an efficiency rating of 89%. The MSP-450-15 has an Enclosed package type with an operating temperature range of -40C to +70C. It includes a built-in fan for active cooling and its dimensions are 8.58 (L) x 4.13 (W) x 1.61 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL MSP-450-15 Features
View More
For specific information on the MEAN WELL MSP-450-15 please view the datasheet
Other models in the MSP-450 series: 3.3 volt-MSP-450-3.3; 5 volt-MSP-450-5; 7.5 volt-MSP-450-7.5; 12 volt-MSP-450-12; 24 volt-MSP-450-24; 36 volt-MSP-450-36; 48 volt-MSP-450-48
| Price | $172.00 |
|---|---|
| Manufacturer | Mean Well |
| Application | Medical |
| Package Type | Enclosed |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 15 |
| Output Current 1 | 30A |
| Power Output (W) | 450 |
| Length | 8.58in (218.00mm) |
| Width | 4.13in (105.00mm) |
| Height | 1.61in (41.00mm) |
| Cooling | Fan Cooled |
| Operating Temperature | -40C ~ 70C (with derating) |
| Efficiency | 89% |
| Weight (lbs) | 2.623950 |
| Country of Origin | Taiwan, China |
| Product Series | MSP-450 |
Get Help Finding the Right Power Supply: Power Requirement Form
