Mean Well MSP-300-15 (330W 15V)
SKU
MSP-300-15
Authorized MEAN WELL
Stocking Distributor
$123.70
- Buy 5 for $117.80 each and save 5%
- Buy 10 for $112.60 each and save 9%
- Buy 20 for $109.40 each and save 12%
MEAN WELL Single Output, Medical AC-DC Converter, Enclosed Package, 330 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 15VDC, Output Current: 22A, Connection: Screw Terminal
More Details
The MEAN WELL MSP-300-15 is a medical safety certified, single output, AC-DC power supply. The nominal output is 15 volts DC at 22 amps, with a maximum power output of 330 watts. It accepts an AC input voltage of 85~264 and has an efficiency rating of 88%. The MSP-300-15 has an Enclosed package type with an operating temperature range of -40C to +70C. It includes a built-in fan for active cooling and its dimensions are 7.83 (L) x 4.13 (W) x 1.61 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL MSP-300-15 Features
View More
For specific information on the MEAN WELL MSP-300-15 please view the datasheet
Other models in the MSP-300 series: 3.3 volt-MSP-300-3.3; 5 volt-MSP-300-5; 7.5 volt-MSP-300-7.5; 12 volt-MSP-300-12; 24 volt-MSP-300-24; 36 volt-MSP-300-36; 48 volt-MSP-300-48
| Price | $123.70 |
|---|---|
| Manufacturer | Mean Well |
| Application | Medical |
| Package Type | Enclosed |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 15 |
| Output Current 1 | 22A |
| Power Output (W) | 330 |
| Length | 7.83in (199.00mm) |
| Width | 4.13in (105.00mm) |
| Height | 1.61in (41.00mm) |
| Cooling | Fan Cooled |
| Operating Temperature | -40C ~ 70C (with derating) |
| Efficiency | 88% |
| Weight (lbs) | 2.094750 |
| Country of Origin | China |
| Product Series | MSP-300 |
Get Help Finding the Right Power Supply: Power Requirement Form
