Mean Well MPM-45-24ST (45W 24V)
SKU
MPM-45-24ST
Authorized MEAN WELL
Stocking Distributor
$24.30
- Buy 5 for $23.20 each and save 5%
- Buy 10 for $22.10 each and save 9%
- Buy 20 for $21.50 each and save 12%
MEAN WELL Single Output, Medical AC-DC Converter, Enclosed Package, 45 Watts, Input Voltage Range: 80~264VAC, Output Voltage: 24VDC, Output Current: 2A, Connection: Screw Terminal
More Details
The MEAN WELL MPM-45-24ST is a medical safety certified, single output, AC-DC power supply. The nominal output is 24 Volts DC at 1.88 amps, with a maximum power output of 45 watts. It accepts an AC input voltage of 80~264 and has an efficiency rating of 93%. The MPM-45-24ST has an Enclosed package type with an operating temperature range of -30C to +80C. It has a fanless design for silent operation and its dimensions are 4.29 (L) x 2.05 (W) x 1.32 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL MPM-45-24ST Features
View More
For specific information on the MEAN WELL MPM-45-24ST please view the datasheet
Other models in the MPM-45-ST series: 5 volt-MPM-45-5ST; 12 volt-MPM-45-12ST; 15 volt-MPM-45-15ST; 48 volt-MPM-45-48ST
| Price | $24.30 |
|---|---|
| Manufacturer | Mean Well |
| Application | Medical |
| Package Type | Enclosed |
| AC Input (VAC) | 80~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 24 |
| Output Current 1 | 1.88A |
| Power Output (W) | 45 |
| Length | 4.29in (109.00mm) |
| Width | 2.05in (52.00mm) |
| Height | 1.32in (33.50mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 80C (with derating) |
| Efficiency | 93% |
| Weight (lbs) | 0.454230 |
| Country of Origin | China |
| Product Series | MPM-45-ST |
Get Help Finding the Right Power Supply: Power Requirement Form
