Mean Well MDS01N-12 (1W 12V)
SKU
MDS01N-12
Authorized MEAN WELL
Stocking Distributor
$5.22
- Buy 5 for $5.14 each and save 2%
- Buy 10 for $5.11 each and save 2%
- Buy 20 for $5.03 each and save 4%
MEAN WELL Single Output Medical DC-DC Converter, SIP Package, On Board Package, 1 Watts, Input Voltage Range: 21.6~26.4VDC, Output Voltage: 12VDC, Output Current: 84mA
More Details
The MEAN WELL MDS01N-12 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 21.6 VDC and 26.4 VDC with a nominal input of 24 Volts. The MDS01N-12 has a 12 Volt Output at 0.084 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01N-12, DC-DC converter, has a Board Mount SIP package type and its dimensions are 0.77 (L) x 0.39 (W) x 0.49 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL MDS01N-12 Features
View More
For specific information on the MEAN WELL MDS01N-12 please view the datasheet
Other models in the MDS01 series: 5Vdc in, 3.3Vdc out-MDS01L-03;, 5Vdc in, 5Vdc out-MDS01L-05;, 5Vdc in, 12Vdc out-MDS01L-12;, 5Vdc in, 15Vdc out-MDS01L-15;, 12Vdc in, 5Vdc out-MDS01M-05;, 12Vdc in, 12Vdc out-MDS01M-12;, 12Vdc in, 15Vdc out-MDS01M-15;, 24Vdc in, 5Vdc out-MDS01N-05;, 24Vdc in, 15Vdc out-MDS01N-15;
| Price | $5.22 |
|---|---|
| Manufacturer | Mean Well |
| Application | Medical |
| Package Type | Board Mount, SIP |
| Power Output (W) | 1 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 21.6~26.4 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current 1 | 84mA |
| Length | 0.77in (19.56mm) |
| Width | 0.39in (9.91mm) |
| Height | 0.49in (12.45mm) |
| Operating Temperature | -40C ~ 85C (with derating) |
| Weight (lbs) | 0.020000 |
| Product Series | MDS01 |
