AC-DC Power Supplies by Integrated Power Designs

Discover the reliability of AC-DC power supplies from Integrated Power Designs (IPD), available at Bravo Electro. Manufactured entirely in the USA, these tariff-free units range from 62 to 1000 watts, delivering consistent power for demanding applications. Since 1985, IPD has crafted solutions for medical equipment, industrial automation, and audio/video systems, blending efficiency with American-made quality.

Features of IPD AC-DC Power Supplies

IPD’s AC-DC power supplies offer 1 to 4 output options with voltages from 3.3V to 48V, perfect for multi-component setups. With peak efficiency up to 90%, they reduce energy costs while meeting rigorous standards like IEC 60601-1 for medical safety. Features like overcurrent protection and low ripple noise ensure stable performance, whether in open-frame or enclosed designs—all tariff-free to keep your budget intact.

Power Your Industry with IPD

From powering life-saving medical devices to driving industrial machinery, these AC-DC units excel where precision matters. IPD’s in-house engineering and ISO 9001:2015 certification guarantee top-tier craftsmanship. Shop this tariff-free advantage at Bravo Electro and elevate your projects with U.S.-made excellence. Use our web chat or call us (408-733-9090) for custom configurations!

View as List Grid

Items 1-15 of 801

Set Descending Direction
  1. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 7.5/ -7.5/ 12/ 12VDC, Output Current: 3/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4010-CHCO is a quad output, AC-DC power supply. The four outputs are 7.5V / 3A, -7.5V / 2A, 12V / 2A, 12V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4010-CHCO is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  2. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 7.5/ -7.5/ 12/ 12VDC, Output Current: 3/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4010-CH is a quad output, AC-DC power supply. The four outputs are 7.5V / 3A, -7.5V / 2A, 12V / 2A, 12V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4010-CH is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  3. IPD Quad Output AC-DC Converter, Open Frame Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 7.5/ -7.5/ 12/ 12VDC, Output Current: 3/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4010 is a quad output, AC-DC power supply. The four outputs are 7.5V / 3A, -7.5V / 2A, 12V / 2A, 12V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4010 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.5 (L) x 2.5 (W) x 1.22 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  4. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 6.7/ 5/ 15/ -15VDC, Output Current: 5/ 4/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4009-CHCO is a quad output, AC-DC power supply. The four outputs are 6.7V / 5A, 5V / 4A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4009-CHCO is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  5. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 6.7/ 5/ 15/ -15VDC, Output Current: 5/ 4/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4009-CH is a quad output, AC-DC power supply. The four outputs are 6.7V / 5A, 5V / 4A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4009-CH is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  6. IPD Quad Output AC-DC Converter, Open Frame Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 6.7/ 5/ 15/ -15VDC, Output Current: 5/ 4/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4009 is a quad output, AC-DC power supply. The four outputs are 6.7V / 5A, 5V / 4A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4009 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.5 (L) x 2.5 (W) x 1.22 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  7. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ 24/ 15/ -15VDC, Output Current: 6/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4007-CHCO is a quad output, AC-DC power supply. The four outputs are 5V / 6A, 24V / 2A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4007-CHCO is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  8. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ 24/ 15/ -15VDC, Output Current: 6/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4007-CH is a quad output, AC-DC power supply. The four outputs are 5V / 6A, 24V / 2A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4007-CH is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  9. IPD Quad Output AC-DC Converter, Open Frame Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ 24/ 15/ -15VDC, Output Current: 6/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4007 is a quad output, AC-DC power supply. The four outputs are 5V / 6A, 24V / 2A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4007 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.5 (L) x 2.5 (W) x 1.22 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  10. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ 24/ 12/ -12VDC, Output Current: 6/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4006-CHCO is a quad output, AC-DC power supply. The four outputs are 5V / 6A, 24V / 2A, 12V / 2A, -12V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4006-CHCO is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  11. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ 24/ 12/ -12VDC, Output Current: 6/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4006-CH is a quad output, AC-DC power supply. The four outputs are 5V / 6A, 24V / 2A, 12V / 2A, -12V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4006-CH is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  12. IPD Quad Output AC-DC Converter, Open Frame Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ 24/ 12/ -12VDC, Output Current: 6/ 2/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4006 is a quad output, AC-DC power supply. The four outputs are 5V / 6A, 24V / 2A, 12V / 2A, -12V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.5 (L) x 2.5 (W) x 1.22 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  13. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ -5/ 15/ -15VDC, Output Current: 6/ 5/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4005-CHCO is a quad output, AC-DC power supply. The four outputs are 5V / 6A, -5V / 5A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4005-CHCO is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  14. IPD Quad Output AC-DC Converter, Enclosed Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ -5/ 15/ -15VDC, Output Current: 6/ 5/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4005-CH is a quad output, AC-DC power supply. The four outputs are 5V / 6A, -5V / 5A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4005-CH is an Enclosed package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.79 (L) x 2.62 (W) x 1.48 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
  15. IPD Quad Output AC-DC Converter, Open Frame Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ -5/ 15/ -15VDC, Output Current: 6/ 5/ 2/ 2A

    More Details
    The Integrated Power Designs REL-70-4005 is a quad output, AC-DC power supply. The four outputs are 5V / 6A, -5V / 5A, 15V / 2A, -15V / 2A for a total power output of 70 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-4005 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.5 (L) x 2.5 (W) x 1.22 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
