Mean Well LRS-50-48 (53W 48V)
SKU
LRS-50-48
Authorized MEAN WELL
Stocking Distributor
$12.20
- Buy 5 for $11.60 each and save 5%
- Buy 10 for $11.10 each and save 9%
- Buy 20 for $10.80 each and save 11%
MEAN WELL Single Output, Industrial AC-DC Converter, Enclosed Package, 53 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 48VDC, Output Current: 1A, Connection: Screw Terminal
More Details
The MEAN WELL LRS-50-48 is a industrial, single output, AC-DC power supply. The nominal output is 48 Volts DC at 1.1 amps, with a maximum power output of 53 watts. It accepts an AC input voltage of 85~264 and has an efficiency rating of 90%. The LRS-50-48 has an Enclosed package type with an operating temperature range of -30C to +70C. It has a fanless design for silent operation and its dimensions are 3.90 (L) x 3.23 (W) x 1.18 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL LRS-50-48 Features
View More
For specific information on the MEAN WELL LRS-50-48 please view the datasheet
Other models in the LRS-50 series: 3.3 volt-LRS-50-3.3; 5 volt-LRS-50-5; 12 volt-LRS-50-12; 15 volt-LRS-50-15; 24 volt-LRS-50-24; 36 volt-LRS-50-36
| Price | $12.20 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 48 |
| Output Current 1 | 1.1A |
| Power Output (W) | 53 |
| Length | 3.90in (99.00mm) |
| Width | 3.23in (82.00mm) |
| Height | 1.18in (30.00mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 90% |
| Weight (lbs) | 0.507150 |
| Country of Origin | China |
| Product Series | LRS-50 |
Get Help Finding the Right Power Supply: Power Requirement Form
