Mean Well IRM-20-3.3

SKU
IRM-20-3.3
Image at top has 5 yellow stars, below it is the red Mean Well logo.Image at top has 5 yellow stars, below it is the red Mean Well logo.

  Authorized MEAN WELL

  Stocking Distributor

$9.12
  • Buy 5 for $8.69 each and save 5%
  • Buy 10 for $8.30 each and save 9%
  • Buy 20 for $8.06 each and save 12%

Product images shown are for illustration purposes only and may not be an exact representation of the product.

MEAN WELL AC-DC Industrial On Board 15 Watts 3.3VDC out

More Details
The MEAN WELL IRM-20-3.3 is a industrial, single output, AC-DC power supply. The nominal output is rated for 3.3 volts DC at 4.5 amps (15 watts). This power converter accepts an AC input range of 85~305 and has an efficiency rating of 76%. The IRM-20-3.3 is an On Board package type with an operating temperature range of -30C to +70C. This AC-DC converter has no on board fan and its dimensions are 52.4 (L) x 27.2 (W) x 24 (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through email, online chat or call us (408-733-9090).

MEAN WELL IRM-20-3.3

AC-DC Industrial On Board Single output power supplyOutput: 3.3 volts, 4.5 amps, 15 wattsUniversal AC input / Full rangeNo load power consumption <0.1W

View MoreCompact sizeProtections: Short circuit / Overload / Over voltageCooling by free air convectionIsolation Class IIHigh reliability, low cost3 year warranty

For specific information on the MEAN WELL IRM-20-3.3 please view the datasheet

Other models in the IRM-20 series: 5 volt-IRM-20-5; 12 volt-IRM-20-12; 15 volt-IRM-20-15; 24 volt-IRM-20-24

More Information
Price$9.12
ManufacturerMean Well
Package TypeOn Board
IndustryIndustrial
AC InputUniversal Input - Full Range, Up to 305, 85~305
Voltage Output3.3
Power Output (W)15
CoolingNo On Board Fan
IRM-20_spec (718.49 kB)
