Mean Well HRPG-600-12

Image at top has 5 yellow stars, below it is the red Mean Well logo.Image at top has 5 yellow stars, below it is the red Mean Well logo.

  Authorized MEAN WELL

  Stocking Distributor

  • Buy 5 for $145.71 each and save 5%
  • Buy 10 for $139.27 each and save 9%
  • Buy 20 for $135.24 each and save 12%

Product images shown are for illustration purposes only and may not be an exact representation of the product.

MEAN WELL AC-DC Industrial Enclosed 636 Watts 12VDC out

More Details
The MEAN WELL HRPG-600-12 is a industrial, single output, AC-DC power supply. The nominal output is rated for 12 Volts DC at 53 amps (636 watts). This power converter accepts an AC input range of 85~264 and has an efficiency rating of 88%. The HRPG-600-12 is an Enclosed package type with an operating temperature range of -40C to +70C. This AC-DC converter has on board fan and its dimensions are 218 (L) x 105 (W) x 63.5 (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).

MEAN WELL HRPG-600-12 Features

AC-DC Industrial Enclosed Single output power supplyOutput: 12 volts, 53 amps, 636 wattsUniversal AC input / Full rangeBuilt-in active PFC function, PF>0.94

View MoreHigh efficiency up to 89%Withstand 300VAC surge input for 5 secondsProtections: Short circuit / Overload / Over voltage / Over temperatureBuilt-in cooling fan ON-OFF controlBuilt-in DC OK signalBuilt-in remote ON-OFF controlStandby 5V@0.3ABuilt-in remote sense functionNo load power consumption<0.75WCurrent sharing up to 2400W (3+1) (24V,36V,48V)5 years warranty

For specific information on the MEAN WELL HRPG-600-12 please view the datasheet

Other models in the HRPG-600 series: 3.3 volt-HRPG-600-3.3; 5 volt-HRPG-600-5; 7.5 volt-HRPG-600-7.5; 15 volt-HRPG-600-15; 24 volt-HRPG-600-24; 36 volt-HRPG-600-36; 48 volt-HRPG-600-48

More Information
ManufacturerMean Well
Package TypeEnclosed
AC InputUniversal Input - Full Range, 85~264
Voltage Output12.0
Power Output (W)636
CoolingOn Board Fan
HRPG-600_spec (1.03 MB)
