Mean Well HRP-300-3.3 (198W 3.3V)
SKU
HRP-300-3.3
Authorized MEAN WELL
Stocking Distributor
$85.50
- Buy 5 for $81.50 each and save 5%
- Buy 10 for $77.90 each and save 9%
- Buy 20 for $75.60 each and save 12%
MEAN WELL Single Output, Industrial AC-DC Converter, Enclosed Package, 198 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 3.3VDC, Output Current: 60A, Connection: Screw Terminal
More Details
The MEAN WELL HRP-300-3.3 is a industrial, single output, AC-DC power supply. The nominal output is 3.3 volts DC at 60 amps, with a maximum power output of 198 watts. It accepts an AC input voltage of 85~264 and has an efficiency rating of 80%. The HRP-300-3.3 has an Enclosed package type with an operating temperature range of -40C to +70C. It includes a built-in fan for active cooling and its dimensions are 7.83 (L) x 4.13 (W) x 1.61 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL HRP-300-3.3 Features
View More
For specific information on the MEAN WELL HRP-300-3.3 please view the datasheet
Other models in the HRP-300 series: 5 volt-HRP-300-5; 7.5 volt-HRP-300-7.5; 12 volt-HRP-300-12; 15 volt-HRP-300-15; 24 volt-HRP-300-24; 36 volt-HRP-300-36; 48 volt-HRP-300-48
| Price | $85.50 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 3.3 |
| Output Current 1 | 60A |
| Power Output (W) | 198 |
| Length | 7.83in (199.00mm) |
| Width | 4.13in (105.00mm) |
| Height | 1.61in (41.00mm) |
| Cooling | Fan Cooled |
| Operating Temperature | -40C ~ 70C (with derating) |
| Efficiency | 80% |
| Weight (lbs) | 2.094750 |
| Country of Origin | China |
| Product Series | HRP-300 |
Get Help Finding the Right Power Supply: Power Requirement Form
