Mean Well HEP-100-48A (96W 48V)
SKU
HEP-100-48A
Authorized MEAN WELL
Stocking Distributor
$84.00
- Buy 5 for $80.00 each and save 5%
- Buy 10 for $76.50 each and save 9%
- Buy 20 for $74.30 each and save 12%
MEAN WELL Single Output, Industrial AC-DC Converter, Harsh Environment Package, 96 Watts, Input Voltage Range: 90~305VAC, Output Voltage: 48VDC, Output Current: 2A, Connection: Wire Leads
More Details
The MEAN WELL HEP-100-48A is a industrial, single output, AC-DC power supply. The nominal output is 48 Volts DC at 2 amps, with a maximum power output of 96 watts. It accepts an AC input voltage of 90~305 and has an efficiency rating of 93%. The HEP-100-48A has a Harsh Environment package type with an operating temperature range of -55C to +70C. It has a fanless design for silent operation and its dimensions are 8.66 (L) x 2.68 (W) x 1.53 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL HEP-100-48A Features
View More
For specific information on the MEAN WELL HEP-100-48A please view the datasheet
Other models in the HEP-100 (A-Type) series: 12 volt-HEP-100-12A; 15 volt-HEP-100-15A; 24 volt-HEP-100-24A; 36 volt-HEP-100-36A; 54 volt-HEP-100-54A
| Price | $84.00 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Harsh Environment |
| AC Input (VAC) | 90~305 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 48 |
| Output Current 1 | 2.00A |
| Power Output (W) | 96 |
| Length | 8.66in (220.00mm) |
| Width | 2.68in (68.00mm) |
| Height | 1.53in (38.80mm) |
| Cooling | Fanless |
| Operating Temperature | -55C ~ 70C (with derating) |
| Efficiency | 93% |
| Weight (lbs) | 2.469600 |
| Country of Origin | China |
| Product Series | HEP-100 (A-Type) |
Get Help Finding the Right Power Supply: Power Requirement Form
