Mean Well GSM90A24-P1M (90W 24V)
SKU
GSM90A24-P1M
Authorized MEAN WELL
Stocking Distributor
$35.00
- Buy 5 for $33.30 each and save 5%
- Buy 10 for $31.80 each and save 9%
- Buy 20 for $30.90 each and save 12%
MEAN WELL Single Output, Medical AC-DC Converter, External-Desktop Package, 90 Watts, Input Voltage Range: 80~264VAC, Output Voltage: 24VDC, Output Current: 4A, Connection: Barrel Plug - 2.5 x 5.5 x 11mm
More Details
The MEAN WELL GSM90A24-P1M is a medical safety certified, single output, AC-DC power supply. The nominal output is 24 Volts DC at 3.75 amps, with a maximum power output of 90 watts. It accepts an AC input voltage of 80~264 and has an efficiency rating of 90%. The GSM90A24-P1M has an External or Adapter package type with an operating temperature range of -30C to +70C. It has a fanless design for silent operation and its dimensions are 5.71 (L) x 2.36 (W) x 1.26 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL GSM90A24-P1M Features
View More
For specific information on the MEAN WELL GSM90A24-P1M please view the datasheet
Other models in the GSM90A series: 12 volt-GSM90A12-P1M; 15 volt-GSM90A15-P1M; 19 volt-GSM90A19-P1M; 48 volt-GSM90A48-P1M
| Price | $35.00 |
|---|---|
| Manufacturer | Mean Well |
| Application | Medical |
| Package Type | External-Desktop |
| AC Input (VAC) | 80~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 24 |
| Output Current 1 | 3.75A |
| Power Output (W) | 90 |
| Length | 5.71in (145.00mm) |
| Width | 2.36in (60.00mm) |
| Height | 1.26in (32.00mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 90% |
| Weight (lbs) | 0.992250 |
| Country of Origin | China |
| Product Series | GSM90A |
Get Help Finding the Right Power Supply: Power Requirement Form
