Mean Well GSM40B18-P1J (40W 18V)
SKU
GSM40B18-P1J
Authorized MEAN WELL
Stocking Distributor
$21.70
- Buy 5 for $20.60 each and save 5%
- Buy 10 for $19.70 each and save 9%
- Buy 20 for $19.20 each and save 12%
MEAN WELL Single Output, Medical AC-DC Converter, External-Desktop Package, 40 Watts, Input Voltage Range: 80~264VAC, Output Voltage: 18VDC, Output Current: 2A, Connection: Barrel Plug - 2.1 x 5.5 x 11mm
More Details
The MEAN WELL GSM40B18-P1J is a medical safety certified, single output, AC-DC power supply. The nominal output is 18 volts DC at 2.22 amps, with a maximum power output of 40 watts. It accepts an AC input voltage of 80~264 and has an efficiency rating of 89%. The GSM40B18-P1J has an External or Adapter package type with an operating temperature range of -30C to +70C. It has a fanless design for silent operation and its dimensions are 4.92 (L) x 1.97 (W) x 1.24 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL GSM40B18-P1J Features
View More
For specific information on the MEAN WELL GSM40B18-P1J please view the datasheet
Other models in the GSM40B series: 5 volt-GSM40B05-P1J; 7.5 volt-GSM40B07-P1J; 9 volt-GSM40B09-P1J; 12 volt-GSM40B12-P1J; 15 volt-GSM40B15-P1J; 24 volt-GSM40B24-P1J; 48 volt-GSM40B48-P1J
| Price | $21.70 |
|---|---|
| Manufacturer | Mean Well |
| Application | Medical |
| Package Type | External-Desktop |
| AC Input (VAC) | 80~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 18 |
| Output Current 1 | 2.22A |
| Power Output (W) | 40 |
| Length | 4.92in (125.00mm) |
| Width | 1.97in (50.00mm) |
| Height | 1.24in (31.50mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 89% |
| Weight (lbs) | 0.705600 |
| Country of Origin | China |
| Product Series | GSM40B |
Get Help Finding the Right Power Supply: Power Requirement Form
