IPD GRN-110-2001 (2 Output, 110W)
SKU
GRN-110-2001
$89.96
- Buy 5 for $88.15 each and save 2%
- Buy 10 for $85.84 each and save 5%
- Buy 20 for $84.19 each and save 6%
IPD Dual Output AC-DC Converter, Open Frame Package, 110 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 5/ 24VDC, Output Current: 12/ 3A
More Details
The Integrated Power Designs GRN-110-2001 is a dual output, AC-DC power supply. The two outputs are 5V / 12A, 24V / 3A for a total power output of 110 watts. It accepts an AC input range of 85~264 and has an efficiency rating of 85%. The GRN-110-2001 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, features fanless design for quiet operation and its dimensions are 5 (L) x 3 (W) x 1.25 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).
Integrated Power Designs GRN-110-2001 Features
View More
For specific information on the IPD GRN-110-2001 please view the datasheet
Other dual output models in the GRN-110 series: 5V / 12V-GRN-110-2002; 12V / -12V-GRN-110-2003; 15V / -15V-GRN-110-2004; 19V / 12V-GRN-110-2005
| Price | $89.96 |
|---|---|
| Manufacturer | IPD |
| Application | Industrial (ITE), Medical |
| Package Type | Open Frame |
| Number Outputs | 2 |
| Power Output (W) | 110 |
| Voltage - Output 1 (VDC) | 5 |
| Output Current 1 | 12A |
| Voltage - Output 2 (VDC) | 24 |
| Output Current 2 | 3A |
| Length | 5.00in (126.50mm) |
| Width | 3.00in (75.90mm) |
| Height | 1.25in (31.63mm) |
| Operating Temperature | 0C ~ 70C (with derating) |
| Cooling | Fanless |
| Efficiency | 85% |
| Weight (lbs) | 0.800000 |
| Country of Origin | U.S.A. |
| Product Series | GRN-110 |
Get Help Finding the Right Power Supply: Power Requirement Form
