Mean Well GEM06I05-P1J (6W 5V)
SKU
GEM06I05-P1J
Authorized MEAN WELL
Stocking Distributor
$12.54
- Buy 5 for $11.95 each and save 5%
- Buy 10 for $11.42 each and save 9%
- Buy 20 for $11.09 each and save 12%
MEAN WELL Single Output, Medical AC-DC Converter, External-Wall Mount Package, 6 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 5VDC, Output Current: 1A, Connection: Barrel Plug - 2.1 x 5.5 x 11mm
More Details
The MEAN WELL GEM06I05-P1J is a medical safety certified, single output, AC-DC power supply. The nominal output is 5 volts DC at 1.2 amps, with a maximum power output of 6 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 70%. The GEM06I05-P1J has an External or Adapter package type with an operating temperature range of -20C to +70C. It has a fanless design for silent operation and its dimensions are 2.91 (L) x 1.54 (W) x 1.91 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL GEM06I05-P1J Features
View More
For specific information on the MEAN WELL GEM06I05-P1J please view the datasheet
Other models in the GEM06I series: 6 volt-GEM06I06-P1J; 7.5 volt-GEM06I07-P1J; 9 volt-GEM06I09-P1J; 12 volt-GEM06I12-P1J; 15 volt-GEM06I15-P1J; 18 volt-GEM06I18-P1J; 24 volt-GEM06I24-P1J
| Price | $12.54 |
|---|---|
| Manufacturer | Mean Well |
| Application | Medical |
| Package Type | External-Wall Mount |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 5 |
| Output Current 1 | 1.2A |
| Power Output (W) | 6 |
| Length | 2.91in (73.90mm) |
| Width | 1.54in (39.00mm) |
| Height | 1.91in (48.50mm) |
| Cooling | Fanless |
| Operating Temperature | -20C ~ 70C (with derating) |
| Efficiency | 70% |
| Weight (lbs) | 0.264600 |
| Product Series | GEM06I |
Get Help Finding the Right Power Supply: Power Requirement Form
