Mean Well GC120A24-R7B (120W 27.2V)
SKU
GC120A24-R7B
Authorized MEAN WELL
Stocking Distributor
$42.60
- Buy 5 for $40.50 each and save 5%
- Buy 10 for $38.80 each and save 9%
- Buy 20 for $37.60 each and save 12%
MEAN WELL Single Output, Battery Charger AC-DC Converter, External-Desktop Package, 120 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 27.2VDC, Output Current: 4A, Connection: 4-pin DIN Kycon equivalent plug
More Details
The MEAN WELL GC120A24-R7B is a battery charger, single output, AC-DC power supply. The nominal output is 27.2 volts DC at 4.42 amps, with a maximum power output of 120 watts. It accepts an AC input voltage of 85~264 and has an efficiency rating of 90%. The GC120A24-R7B has an External or Adapter package type with an operating temperature range of -30C to +70C. It has a fanless design for silent operation and its dimensions are 6.57 (L) x 2.64 (W) x 1.38 (H) inches. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL GC120A24-R7B Features
View More
For specific information on the MEAN WELL GC120A24-R7B please view the datasheet
Other models in the GC120A series: 13.6 volt-GC120A12-R7B; 54.4 volt-GC120A48-R7B; 13.6 volt-GC120A12-AD1; 27.2 volt-GC120A24-AD1; 54.4 volt-GC120A48-AD1
| Price | $42.60 |
|---|---|
| Manufacturer | Mean Well |
| Application | Battery Charger |
| Package Type | External-Desktop |
| AC Input (VAC) | 85~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 27.2 |
| Output Current 1 | 4.42A |
| Power Output (W) | 120 |
| Length | 6.57in (167.00mm) |
| Width | 2.64in (67.00mm) |
| Height | 1.38in (35.00mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 90% |
| Weight (lbs) | 1.433250 |
| Country of Origin | China |
| Product Series | GC120A |
Get Help Finding the Right Power Supply: Power Requirement Form
