Delta DRF-48V480W3GTA (480W 48V)
- Buy 20 for $181.54 each and save 3%
- Buy 50 for $178.41 each and save 4%
- Buy 100 for $175.61 each and save 6%
Delta Single Output, Conformal Coating, Industrial AC-DC Converter, DIN Rail Package, 480 Watts, Input Voltage Range: 320~575 (3-Phase/2-Phase)VAC, Output Voltage: 48VDC, Output Current: 10A, Connection: Spring Clamp Terminal (T)
More Details
The Delta DRF-48V480W3GTA is a industrial, 1 output, AC-DC power supply. The nominal output is 48 Volts DC at 10 amps, with a maximum power output of 480 watts. It accepts an AC input voltage of 320~575 (3-Phase/2-Phase) and has an efficiency rating of 94%. The DRF-48V480W3GTA has a DIN Rail mount package type with an operating temperature range of -40C to +70C. It features a fanless design for silent operation and its dimensions are 4.88 (L) x 2.56 (W) x 5.01 (H) inches. If you have questions about this Delta AC-DC power supply please contact us through our web chat or call us (408-733-9090).
Delta DRF-48V480W3GTA Features
View More
DRF-480WT (3-Phase) Series Description: The Delta DRF-480WT (3-Phase) Series AC-DC DIN rail power supply, a high-capacity model in the Force-GT family, delivers a powerful 480-watt output with voltage options of 24V and 48V, featuring a conformal coating to protect against dust, pollutants, and corrosive elements in demanding industrial environments. Equipped with tool-free spring clamp terminals for fast, secure, and vibration-resistant connections, this unit is engineered for 3-phase (320-575Vac) or 2-phase (340-575Vac) AC input systems (see datasheet for derating), making it ideal for applications like advanced industrial automation, high-power renewable energy converters, and large-scale material handling systems. Its exceptional power density and efficiency, paired with a fanless, convection-cooled design, ensure reliable performance from -30°C to +70°C, with full power sustained up to +50°C at rated input. The constant current mode with overcurrent protection is optimized for charging high-capacity battery banks and driving capacitive loads in systems such as automated warehouse robotics. Certified to IEC/EN/UL 62368-1 safety standards and RoHS-compliant, the DRF-480WT (3-Phase) meets stringent global environmental and regulatory requirements. It also complies with EN 61000-6-4 Class B emission and EN 61000-6-2 immunity standards, minimizing electromagnetic interference in complex industrial settings. Compact, DIN rail mountable, and designed for seamless installation, this power supply is a top tier solution for engineers seeking a durable, high-efficiency, 3-phase compatible power source with user-friendly connectivity for critical industrial applications.
For specific information on the Delta DRF-48V480W3GTA please view the datasheet
Other models in the DRF-480WT (3-Phase) series: 24 volt-DRF-24V480W3GTA
| Price | $186.58 |
|---|---|
| Manufacturer | Delta |
| Application | Industrial (ITE) |
| Package Type | DIN Rail |
| AC Input (VAC) | 320~575 (3-Phase/2-Phase) |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 48 |
| Output Current 1 | 10A |
| Power Output (W) | 480 |
| Length | 4.88in (123.95mm) |
| Width | 2.56in (65.02mm) |
| Height | 5.01in (127.25mm) |
| Cooling | Fanless |
| Operating Temperature | -40C ~ 70C (with derating) |
| Efficiency | 94% |
| Weight (lbs) | 2.650000 |
| Country of Origin | India |
| Product Series | DRF-480WT (3-Phase) |
