Delta DRF-48V240W1GBA (240W 48V)
- Buy 20 for $88.49 each and save 3%
- Buy 50 for $86.96 each and save 4%
- Buy 100 for $85.59 each and save 6%
Delta Single Output, Conformal Coating, Industrial AC-DC Converter, DIN Rail Package, 240 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 48VDC, Output Current: 5A, Connection: Screw Terminal
More Details
The Delta DRF-48V240W1GBA is a industrial, 1 output, AC-DC power supply. The nominal output is 48 Volts DC at 5 amps, with a maximum power output of 240 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 92%. The DRF-48V240W1GBA has a DIN Rail mount package type with an operating temperature range of -30C to +70C. It features a fanless design for silent operation and its dimensions are 4.87 (L) x 1.57 (W) x 4.6 (H) inches. If you have questions about this Delta AC-DC power supply please contact us through our web chat or call us (408-733-9090).
Delta DRF-48V240W1GBA Features
View More
DRF-240W Series Description: The Delta DRF-240W Series AC-DC DIN rail power supplies, part of the Force-GT family, deliver a robust 240-watt output with voltage options of 12V, 24V, and 48V, featuring a conformal coating to ensure resilience against dust, pollutants, and harsh industrial conditions. Engineered for high-demand applications such as renewable energy systems, industrial robotics, and heavy-duty telecommunications equipment, these units offer exceptional power density and efficiency to support critical operations. With a universal AC input range (85-264V) and a fanless, convection-cooled design, the DRF-240W Series maintains reliable performance from -30°C to +70°C, delivering full power up to +50°C at 230 Vac. Its constant current mode with overcurrent protection is optimized for charging applications, making it ideal for battery management systems and capacitive loads in automated machinery. Certified to IEC/EN/UL 62368-1 safety standards and RoHS-compliant, these power supplies meet rigorous global environmental and regulatory requirements. They also adhere to EN 61000-6-4 Class B emission and EN 61000-6-2 immunity standards, ensuring low electromagnetic interference in challenging industrial settings. Compact, DIN rail-mountable, and designed for long-term durability, the DRF-240W Series provides engineers with a high-efficiency, rugged power solution for complex industrial environments.
For specific information on the Delta DRF-48V240W1GBA please view the datasheet
Other models in the DRF-240W series: 12 volt-DRF-12V240W1GBA; 24 volt-DRF-24V240W1GBA
| Price | $90.94 |
|---|---|
| Manufacturer | Delta |
| Application | Industrial (ITE) |
| Package Type | DIN Rail |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 48 |
| Output Current 1 | 5A |
| Power Output (W) | 240 |
| Length | 4.87in (123.70mm) |
| Width | 1.57in (39.88mm) |
| Height | 4.60in (116.84mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 92% |
| Weight (lbs) | 1.410000 |
| Country of Origin | India |
| Product Series | DRF-240W |
Get Help Finding the Right Power Supply: Power Requirement Form
