Delta DRF-24V120W1GBA (120W 24V)
- Buy 20 for $62.41 each and save 3%
- Buy 50 for $61.33 each and save 4%
- Buy 100 for $60.37 each and save 6%
Delta Single Output, Conformal Coating, Industrial AC-DC Converter, DIN Rail Package, 120 Watts, Input Voltage Range: 90~264VAC, Output Voltage: 24VDC, Output Current: 5A, Connection: Screw Terminal
More Details
The Delta DRF-24V120W1GBA is a industrial, 1 output, AC-DC power supply. The nominal output is 24 Volts DC at 5 amps, with a maximum power output of 120 watts. It accepts an AC input voltage of 90~264 and has an efficiency rating of 91%. The DRF-24V120W1GBA has a DIN Rail mount package type with an operating temperature range of -30C to +70C. It features a fanless design for silent operation and its dimensions are 4.87 (L) x 1.18 (W) x 4.6 (H) inches. If you have questions about this Delta AC-DC power supply please contact us through our web chat or call us (408-733-9090).
Delta DRF-24V120W1GBA Features
View More
DRF-120W Series Description: The Delta DRF-120W Series AC-DC DIN rail power supplies, part of the Force-GT family, deliver a reliable 120-watt output with voltage options of 12V, 24V, and 48V, featuring a conformal coating to safeguard against dust, pollutants, and harsh industrial conditions. Tailored for rugged applications like chemical plants, telecommunications infrastructure, and outdoor industrial setups, these units combine high power density with exceptional efficiency to ensure consistent performance. With a universal AC input range (85-264V) and fanless, convection-cooled design, the DRF-120W Series operates reliably from -30°C to +70°C, maintaining full power up to +50°C at 230 Vac. Its constant current mode overcurrent protection makes it ideal for charging applications and powering inductive loads, such as battery backup systems and motor controls. Certified to IEC/EN/UL 62368-1 safety standards and RoHS-compliant, these power supplies meet stringent environmental and regulatory requirements. They also comply with heavy industrial EN 61000-6-4 Class B emission and EN 61000-6-2 immunity standards, ensuring minimal electromagnetic interference. Compact, DIN rail-mountable, and built for durability, the DRF-120W Series offers engineers a versatile, high-efficiency power solution for demanding industrial environments.
For specific information on the Delta DRF-24V120W1GBA please view the datasheet
Other models in the DRF-120W series: 12 volt-DRF-12V120W1GBA; 48 volt-DRF-48V120W1GBA
| Price | $64.14 |
|---|---|
| Manufacturer | Delta |
| Application | Industrial (ITE) |
| Package Type | DIN Rail |
| AC Input (VAC) | 90~264 |
| Number Outputs | 1 |
| Voltage - Output 1 (VDC) | 24 |
| Output Current 1 | 5A |
| Power Output (W) | 120 |
| Length | 4.87in (123.70mm) |
| Width | 1.18in (29.97mm) |
| Height | 4.60in (116.84mm) |
| Cooling | Fanless |
| Operating Temperature | -30C ~ 70C (with derating) |
| Efficiency | 91% |
| Weight (lbs) | 1.100000 |
| Country of Origin | India |
| Product Series | DRF-120W |
Get Help Finding the Right Power Supply: Power Requirement Form
