Mean Well DR-4515

SKU
DR-4515

THIS PRODUCT HAS BEEN DISCONTINUED BY THE MANUFACTURER.  For the suggested replacement, please see the "Related Products" section below.  You can also use our web chat feature or call (408-733-9090) for help.

Image at top has 5 yellow stars, below it is the red Mean Well logo. Image at top has 5 yellow stars, below it is the red Mean Well logo.

  Authorized MEAN WELL

  Stocking Distributor

$19.10
  • Buy 10 for $16.90 each and save 12%

Product images shown are for illustration purposes only and may not be an exact representation of the product.

Add to Wish List Add to Compare
Image emphasizing payment and purchase on this website is secure. Image shows a green shield with a lock, with words saying 100% Secure Image emphasizing payment and purchase on this website is secure. Image shows a green shield with a lock, with words saying 100% Secure

MEAN WELL AC-DC Industrial DIN Rail 42 Watts 15VDC out

More Details
The MEAN WELL DR-4515 is a industrial, single output, AC-DC power supply. The nominal output is rated for 15 volts DC at 2.8 amps (42 watts). This power converter accepts an AC input range of 85~264 and has an efficiency rating of 77%. The DR-4515 is an DIN Rail package type with an operating temperature range of -10C to +50C. This AC-DC converter has no on board fan and its dimensions are 78 W (L) x 93 H (W) x 67 D (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through email, online chat or call us (408-733-9090).
Loading...

MEAN WELL DR-4515

AC-DC Industrial DIN Rail Single output power supplyOutput: 15 volts, 2.8 amps, 42 wattsUniversal AC input/Full rangeProtections: Short circuit / Overload / Over voltage / Over temperature

View MoreCooling by free air convectionCan be installed on DIN rail TS-35/7.5 or 15UL 508 (industrial control equipment) approvedLED indicator for power on100% full load burn-in testFix switching frequency at 100KHz3 year warranty

For specific information on the MEAN WELL DR-4515 please view the datasheet

Other models in the DR-45 series: 5 volt-DR-4505; 12 volt-DR-4512; 24 volt-DR-4524

More Information
Price$19.10
ManufacturerMean Well
Package TypeDIN Rail
IndustryIndustrial
AC InputUniversal Input - Full Range, 85~264
Voltage Output15.0
Power Output (W)42
CoolingNo On Board Fan
DR-45_spec (449.50 kB)
MEAN WELL AC-DC power supply HDR-60-15
