Mean Well DDRH-45-48DR (45W 48V)
SKU
DDRH-45-48DR
$53.40
- Buy 5 for $50.90 each and save 5%
- Buy 10 for $48.60 each and save 9%
- Buy 20 for $47.20 each and save 12%
MEAN WELL Single Output Industrial DC-DC Converter, DIN Rail Package, 45.024 Watts, Input Voltage Range: 150~1500VDC, Output Voltage: 48VDC, Output Current: 0.938A
More Details
The MEAN WELL DDRH-45-48DR is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 150 VDC and 1500 VDC with a nominal input of 800 volts. The DDRH-45-48DR has a 48 Volt Output at 0.938 amps (45.024 watts). The operating temperature is -40~+80°C and comes with several safety marks including EAC/CE/UKCA. The DDRH-45-48DR, DC-DC converter, has a DIN Rail package type and its dimensions are 5.31 (L) x 2.76 (W) x 1.71 (H) inches. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL DDRH-45-48DR Features
View More
For specific information on the MEAN WELL DDRH-45-48DR please view the datasheet
Other models in the DDRH-45(DR) series: 150~1500Vdc in, 12Vdc out-DDRH-45-12DR;, 150~1500Vdc in, 15Vdc out-DDRH-45-15DR;, 150~1500Vdc in, 24Vdc out-DDRH-45-24DR;
| Price | $53.40 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | DIN Rail |
| Power Output (W) | 45 |
| Number Outputs | 1 |
| Input Voltage Range (VDC) | 150~1500 |
| Voltage - Output 1 (VDC) | 48 |
| Output Current 1 | 0.938A |
| Length | 5.31in (135.00mm) |
| Width | 2.76in (70.00mm) |
| Height | 1.71in (43.50mm) |
| Operating Temperature | -40C ~ 80C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 0.683550 |
| Product Series | DDRH-45(DR) |
Get Help Finding the Right Power Supply: Power Requirement Form
